6
3
2
1
1.
Identify the Front Stabilizer (2), which has
Wheels (17) attached. Attach the Front Stabilizer to
the Frame (1) with two M10 x 85mm Button
Screws (56).
2. Tighten the two Leveling Feet (29) into the bottom of
the Rear Stabilizer (3).
Attach the Rear Stabilizer (3) to the Frame (1) with
two M10 x 85mm Button Screws (56).
3. While another person holds the Handlebar Post (6)
near the Frame (1), connect the Upper Wire
Harness (55) to the Lower Wire Harness (51). Next,
pull the excess Upper Wire Harness out of the top of
the Handlebar Post, and slide the Handlebar Post
onto the Frame. Be careful not to pinch the Wire
Harnesses.
Attach the Handlebar Post (6) to the Frame (1) with
three M10 x 50mm Button Screws (46) and three
M10 Split Washers (63); tighten the two Button
Screws in the front of the Handlebar Post first,
and then tighten the third Button Screw.
1
56
3
29
29
63
63
63
46 46
1
55
51
6
56
1
2
17
To make assembly easier, read the information
on page 5 before you begin assembling the
exercise cycle.
