Compressed Air Connection
WARNING: use extreme caution when connecting or disconnecting
compressed air!!
Before connecting compressed air to the PORT-A-COOL® unit be sure that both the Jet
Fan or Air Mover and the Pump shut-off valves are closed. The air is connected by way of
a Crow’s foot type bayonet connector. This connection is made by placing the matting
together where the rubber seals are touching and then twisting the input hose connector
90 deg. clockwise while pressing the two fittings together. A pin should then be inserted
into the two holes to provide a secure and safe attachment.
AIR DRIVE CONSUMPTION RATES
2
INLET FLOW AIR
PRESSURE RATE FLOW
MODEL#
PAC2K36AD
80 PSI l96 scfm 9,100 cfm
PAC2K24AD 40 PSI 164 scfm 4,898 cfm
PAC2K16AD 40 PSI 83 scfm 2,200 cfm
