PART IDENTIFICATION CHART

Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
refers to the key number of the part, from the PART
LIST on page 14. The number after the dash indicates

the quantity needed for assembly. Note: Some small
parts may have been pre-attached for shipping. If
a part is not in the parts bag, check to see if it has
been pre-attached.

3/8" Nylon Locknut (29)—4

Pedal Arm Spacer (41)—3*

#8 x 3/4" Round Head Screw (16)—10

Weld Spacer (49)—2

5/8” Axle Cap (57)—2*

3/4” Axle Cap (43)—4*

Pivot Bushing (56)—4

1/4" Black Nylon Locknut (55)—2

1/4” x 3/4” Screw (54)—2

Pedal Arm Bushing (42)—4

Handlebar Spacer (39)—2

Rear Pedal Arm Bushing (11)—4

* Extra parts may be included.
