9
Chapter 3 Technical Information
Specifications
LCD Panel PL2011M
Size 20.1"
Display Type Active matrix color TFT LCD
Resolution 1600x1200
Display Dot 1600 x (RGB) x 1200
Display Area (mm) 408.0x306.0 (H x V)
Display Color 16.7M
Brightness 300 cd/m 2 (typical) / 240 cd/m 2 (minimum)
Contrast Ratio 1000:1 (typical)
Response Time
Ta=25°C Tr+Tf=16ms
Gray to Gray: 8ms
Lamp Voltage 744 Vrms (typical)
Lamp Current 7.0 mA rms. (typical)
Viewing Angle Vertical: -85° ~ +85°
Horizontal: -85° ~ +85°
Video
Input Signal
Input Impedance
Polarity
Amplitude
Multi-mode Supported Analog RGB 0.7Vp-p
75 Ohm ± 2%
Positive, Negative
0 - 0.7 ± 0.05 Vp
Horizontal Frequency: 24 ~ 80 KHz
Vertical Frequency: 49 ~ 75 Hz Digital TMDS
TMDS
24~80KHz
49~75 Hz
Audio
Input 500mVrms
Output 2W+2W
Control
Power switch (hard and soft types) On/Off switch with LED indicator
OSD
Brightness
Contrast
Horizontal Position
Vertical Position
Phase
Clock
Display Mode Setup
OSD Format Digital
Digital
Digital
Digital
Digital
Digital
Use EEPROM to save settings in memory
26 characters x 15 rows
Power Management
Mode Power Consumption* AC Input LED Color
On 70W maximum 240 VAC Green
Off 3W maximum 240 VAC Yellow
Soft switch off 3W maximum 240 VAC Dark
Disconnected 3W maximum 240 VAC
Yellow: Standby, Suspend, Off
Dark: Power off
* Meeting VESA DPMS requirements measured from AC Input.
