Philips 19PFL5403 User Manual
Page 2
19PFL5403/60
Flat TV with Digital Crystal Clear
19" LCD integrated digital
Specifications
Product highlights
Picture/Display
•
Aspect ratio:
Widescreen
•
Brightness:
300 cd/m²
•
Contrast ratio (typical):
1000:1
•
Response time (typical):
5 ms
•
Viewing angle:
170º (H) / 160º (V)
•
Diagonal screen size:
19 inch / 48 cm
•
Display screen type:
LCD WXGA+ Active Matrix
TFT
•
Panel resolution:
1440 x 900p
•
Picture enhancement:
3/2 - 2/2 motion pull down,
3D Combfilter, White stretch, Digital Crystal
Clear, Progressive Scan, Smart Picture
•
Screen enhancement:
Anti-Reflection coated
screen
Supported Display Resolution
Sound
•
Output power (RMS):
2 x 3W
•
Sound Enhancement:
Auto Volume Leveller,
Incredible Surround, Smart Sound
•
Sound System:
Mono, Stereo
Convenience
•
Clock:
Sleep Timer, Start timer, Stop timer
•
Connection Enhancement:
Easy link
•
Ease of Installation:
Auto Program Naming,
Automatic Channel Install(ACI), Automatic
Tuning System (ATS), Autostore, Fine Tuning, PLL
Digital Tuning, Plug & Play
•
Ease of Use:
Auto Volume Leveller (AVL), On
Screen Display, Program List, Side Control
•
Electronic Program Guide:
Now + Next EPG, 8
day Electronic Program Guide
•
Picture in Picture:
Text dual screen
•
Remote Control:
TV
•
Remote control type:
RCPF05E08B
•
Screen Format Adjustments:
4:3, Movie expand
14:9, Movie expand 16:9, Subtitle Zoom, Super
Zoom, Widescreen
•
Teletext:
100 page Smart Text
•
Smart mode:
Movie, Personal, Power saver,
Standard, Vivid
Tuner/Reception/Transmission
•
Aerial Input:
75 ohm coaxial (IEC75)
•
TV system:
PAL I, PAL B/G, PAL D/K, SECAM B/
G, SECAM D/K, SECAM L/L'
•
Video Playback:
NTSC, SECAM, PAL
•
DVB:
DVB Terrestrial *
•
Tuner bands:
Hyperband, S-Channel, UHF, VHF
Connectivity
•
Ext 1 Scart:
Audio L/R, CVBS in/out, RGB
•
Ext 2:
S-video in, CVBS in, Audio L/R in
•
Ext 3:
YPbPr, Audio L/R in
•
HDMI 1:
HDMI v1.3
•
HDMI 2:
HDMI v1.3
•
EasyLink (HDMI-CEC):
One touch play, System
standby
•
Other connections:
Headphone out, PC Audio in,
PC-In VGA, S/PDIF out (coaxial), Common
Interface
Power
•
Ambient temperature:
5 °C to 35 °C
•
Mains power:
100-240V, 50/60Hz
•
Power consumption:
50 W
•
Standby power consumption:
<0.3 W
Dimensions
•
Set dimensions (W x H x D):
475 x 334 x 71 mm
•
Set dimensions with stand (W x H x D):
475 x 387 x 160 mm
•
Box dimensions (W x H x D):
567 x 399 x 215 mm
•
VESA wall mount compatible:
100 x 100 mm
Accessories
•
Included Accessories:
Table top stand, Power
cord, Quick start guide, User Manual, Warranty
certificate, Remote Control, Batteries for remote
control
•
•
Computer formats
Resolution
Refresh rate
640 x 480
60Hz
800 x 600
60Hz
1024 x 768
60Hz
•
Video formats
Resolution
Refresh rate
480i
60Hz
480p
60Hz
576i
50Hz
576p
50Hz
720p
50, 60Hz
1080i
50, 60Hz
1080p
50Hz, 60Hz
Issue date 2008-12-05
Version: 1.0.2
12 NC: 8670 000 51765
EAN: 87 12581 47809 4
© 2008 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
Digital Crystal Clear
Digital Crystal Clear is a package of picture innovations
that digitally adjusts and optimizes picture quality to
optimal contrast, color and sharpness levels. It's like
watching vivid cinema-like images.
LCD display, 1440 x 900p
This WXGA+ display with state-of-the-art LCD screen
technology gives you widescreen HD resolution of 1440
x 900p pixels. It produces brilliant flicker-free progressive
scan pictures with optimum brightness and superb colors.
This vibrant and sharp image will provide you with an
enhanced viewing experience.
HD Ready
Enjoy the exceptional picture quality of High Definition
pictures and be fully prepared for HD sources like HDTV
settop box or Blu-ray disc. HD Ready is a protected label
that offers picture quality beyond that of progressive
scan. It conforms to strict standards laid out by EICTA to
offer a HD screen that displays the benefits of resolution
and picture quality of a High Definition signal. It has a
universal connection for both analog YPbPr and
uncompressed Digital connection of DVI or HDMI,
supporting HDCP. It can display 720p, and 1080i signals
at 50 and 60Hz.
Integrated Digital DVB-T tuner
The integrated DVB-T tuner lets you receive Digital
Terrestrial TV to watch or record. This means you do not
need an additional set top box and also the additional
cables.
Incredible Surround
Incredible Surround is an audio technology from Philips
that dramatically magnifies the sound field to immerse
you in the audio. Using state-of-the-art electronic phase
shifting, Incredible Surround mixes sounds from left and
right in such a way that it expands the virtual distance
between the two speakers. This wider spread greatly
enhances the stereo effect and creates a more natural
sound dimension. Incredible Surround allows you to
experience total surround with greater depth and width
of sound, without the use of additional speakers.
2 HDMI inputs
HDMI makes an uncompressed digital RGB connection
from the source to the screen. By eliminating conversion
to an analog signal, it delivers an unblemished image. The
non-degraded signal reduces flicker and leads to a clearer
picture. HDMI intelligently communicates the highest
output resolution with the source device. The HDMI input
is fully backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy protection.
With 2 HDMI inputs you can connect multiple HD
sources, for instance an HD settop box, and a Blu-ray
player. Your TV is fully prepared for the HD future.
EasyLink
EasyLink uses the HDMI CEC industry standard protocol
to share functionality between connected devices and the
TV. With EasyLink only one remote control is needed to
operate main functionalities on your TV and connected
devices. EasyLink uses the standard HDMI cable to
transfer system commands. It works between all
electronic devices equipped with HDMI CEC.
PC input (VGA)
With PC input you can connect your TV to a computer by
a VGA cable and use the TV as a PC monitor.
