PAC SWI-JACK - Manual (Page 5)

06-08-09
Programming the SWI-JACK to Control the Head Unit (cont.)
The SWI-JACK must be programmed in the specific order shown in the chart below. If a function is not needed, it may be skipped by
pressing the Program/Mode button 1 time per function in its place. The LED will flash once (indicating the function has been skipped)
and then illuminate, waiting for the next button to be pressed. Adjust the Radio Select switch on the side of the SWI-JACK according to
the chart. Alpine = 1, JVC = 2, Kenwood = 3, Clarion = 4, Valor = 5, OEM = 6 and Blaupunkt = 7.
Alpine JVC Kenwood Clarion Valor OEM Blaupunkt
Radio Select Switch
Setting 1 2 3 4 5 6 7
1 Vol Up Vol Up Vol Up Vol Up Vol Up Vol Up Vol Up
2 Vol Down Vol Down Vol Down Vol Down Vol Down Vol Down Vol Down
3 Mute Mute/Power Mute Mute Mute Mute Mute
4 Preset Up Preset Up Source Track Up Source Source Source
5 Preset Down Source Seek Up Track Down OK Answer Call Track Up
6 Source Seek Up Track Up Band Track Up End Call Track Down
7 Track Up Seek Down Track Down Source Track Down Next Disc Up
8 Track Down Select Disc Up/FM Up Cursor Previous Disc Down
9 Power Band Disc Down/AM Down Cursor Play OK
10 Ent/Play Answer Call Band
11 Band/Program
1
2 3 4 5
6 7
8 9
0
Radio Select Switch located on
the side of SWI-JACK interface
