POLAR SMOOTH AGILE DMT X1 User Manual
Page 6
6
SMOOTH AGILE DMT X1
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
100
101
Console Support Tube
1
X1-101
102
Action Handlebar – Left
1
X1-102
103
Action Handlebar – Right
1
X1-103
104
Moving Linkage – Left
1
X1-104
105
Moving Linkage – Right
1
X1-105
106
Pedal Arm – Left
1
X1-106
107
Pedal Arm – Right
1
X1-107
108
Pedal Swing Arm
2
X1-108
109 Incline
Frame
1
X1-109
110
Incline Transmission Tube-Front
1
X1-110
111
Incline Transmission Tube-Back
1
X1-111
112 Main
Frame
1
X1-112
113
Cover Support Tube
1
X1-113
114
Electro-magnetic System Bracket
1
X1-114
115
Tension Wheel Bracket
1
X1-115
116
Pedal Support Base
2
X1-116
117
Pedal Buffer Set
2
X1-117
200
201
Handlebar Foam Grip
2
X1-201
202 Handlebar
Cap
2
X1-202
203
Hand Pulse Sensor Back Cover
2
X1-203
204
Hand Pulse Sensor Cover
2
X1-204
206
Incline Frame Holder – Rear
2
X1-206
210 Bearing
6004
4
X1-210
211 Bearing
2201
2
X1-211
212 Bearing
608zz
8
X1-212
213
Moving Linkage Bushing
4
X1-213
214 Bearing
6804
4
X1-214
215 Bearing
2203
2
X1-215
216 Pedal
Fixing
Base
4
X1-216
217 Bearing
6205
4
X1-217
218
Bushing 25.6 x 28.6 x 50mm
2
X1-218
219
Bushing 16 x 22.2 x 10.7mm
4
X1-219
220
Bushing 18 x 12mm
2
X1-220
221 Flywheel
Pivot
1
X1-221
222 Bearing
6003
2
X1-222
223 Aluminum
Disk
1
X1-223
224 Flywheel
1
X1-224
225 Bearing
6300
2
X1-225
