5 (E)
ENGLISH
Installing the board
Screw Board clamp
5
Reattach the board clamp using the screw, then fix the
top panel in place using the 2 coin screws.
Specifications
Dimensions (WaHaD):
5a5 7 /
8 a
5 /
8
inch (127a148a15 mm)
Weight:
0.275 lb (125 g)
Analog component input:
BNCa3 (Y, P
B
, P
R
)
Y: 1.0 V [p-p], 75
Ω
P
B
/P
R
:
AJ-YA931G; 0.525/0.757 V [p-p] switchable, 75
Ω
AJ-YA932G; 0.7 V [p-p], 75
Ω
Analog composite input:
BNCa2, loop through, 75
Ω ON/OFF switchable
VIDEO: 1.0 V [p-p], 75
Ω ON
