Loading a disc

% Insert a disc into the disc loading slot.

Playback will automatically start.

# If DVD AUTO PLAY is turned off, touch the

source icon and then touch DVD to select DVD

(refer to the previous page).

# When a disc is loaded in this unit, touch the

source icon and then touch DVD to select DVD.

# To eject a disc, press EJECT.

Notes

! The DVD player plays one, standard, 12-cm or

8-cm (single) disc at a time. Do not use an

adapter when playing 8-cm discs.

! Do not insert anything other than a disc into

the disc loading slot. Discs which can be

played back are listed on Playable discs on

page 8.

! If you cannot insert a disc completely or if

after you insert a disc the disc does not play,

check that the label side of the disc is up.

Press EJECT to eject the disc, and check the

disc for damage before inserting it again.

! If an error message such as ERROR-02 is dis-

played, refer to Error messages on page 99.

Adjusting the volume

% Use VOLUME to adjust the sound level.

With the head unit, rotate VOLUME to in-

crease or decrease the volume.

With the remote control, press VOLUME to in-

crease or decrease the volume.

Turning the unit off

% When using the touch panel keys,

touch the source icon and then touch OFF.

# When the source icon is not displayed, you

can display it by touching the screen.

% When using the button, press SOURCE

and hold until the unit turns off.

Using the rear display

You can watch the video sources (such as

DVD or AV) on rear display independently of

front display.

! To watch a DVD/Video CD on the rear dis-

play only, switch the operation mode on the

remote control to DVD. And you can oper-

ate the DVD/Video CD playback on the rear

display independently by the remote con-

trol. (Refer to page 18.)

CAUTION

When you have turned the rear display output on

by pressing REAR ON, you cannot turn it off even

if you press SOURCE and hold. In this case, press

REAR ON and hold to turn the rear display output

off.

% Press REAR ON to select the video

source on the rear display.

Press REAR ON repeatedly to switch between

the following video sources:

F. SOURCE (same source as the front display)

DVD (built-in DVD player)AV (video input)

Rear display output is turned on and the illu-

mination color of REAR ON changes to a dif-

ferent color from the other buttons.

# You can also perform this operation by press-

ing REAR.S on the remote control.

# To turn the rear display output off, press

REAR ON and hold.

# When selecting F. SOURCE, when the selected

source is an audio source, nothing is displayed

on rear display.

# When you watch DVD (built-in DVD player) on

both the front and the rear display, audio is not

outputted from REAR OUT.

# When selecting FRONT SOURCE in

REAR MODE, audio is not outputted from REAR

OUT. (Refer to Setting the video of rear display on

page 94.)

# When selecting FRONT SOURCE in

REAR MODE, you can select F. SOURCE only.

(Refer to Setting the video of rear display on page

94.)
