Specifications
Specifications (DIN 45 500)
g AMPLIFIER SECTION
RMS output power of each channel driven
10 % total harmonic distortion
1 kHz front CH 90 W per channel (4 Ω)
1 kHz surround CH 90 W per channel (4 Ω)
1 kHz center CH 220 W per channel (6 Ω)
100 Hz subwoofer CH 220 W per channel (6 Ω)
Total RMS output power 800 W
Rated minimum sine wave RMS power output
1% total harmonic distortion (Dolby Digital mode)
1kHz front CH 50 W per channel (4 Ω)
1kHz surround CH 50 W per channel (4 Ω)
1kHz center CH 150 W per channel (6 Ω )
100 Hz subwoofer CH 150 W per channel (6 Ω)
Total RMS output power 500 W
Total harmonic distortion
Half power at 1 kHz (Front CH) 0.5 % (4 Ω)
Input sensitivity
GAME/AUX, TV, DVR/DVD-P 450 mV, IHF'66
MUSIC PORT 250 mV, IHF'66
S/N at rated power (4 Ω)
GAME/AUX, TV, DVR/DVD-P 80 dB (85 dB, IHF'66)
MUSIC PORT 70 dB (85 dB, IHF'66)
Input impedance
GAME/AUX, TV, DVR/DVD-P, MUSIC PORT 47 kΩ
Tone controls
BASS 50 Hz, +10 to -10 dB
TREBLE 20 kHz, +10 to -10 dB
g FM TUNER SECTION
Frequency range 87.50 MHz to 108.00 MHz
Sensitivity
S/N 30 dB 1.9 µV/75 Ω
S/N 26 dB 1.8 µV/75 Ω
S/N 20 dB 1.6 µV/75 Ω
IHF usable sensitivity (IHF '58) 2.2 µV/75 Ω
IHF 46 dB stereo quieting sensitivity 22 µV/75 Ω
Total harmonic distortion
MONO 0.2%
STEREO 0.3%
S/N
MONO 60 dB (71 dB, IHF)
STEREO 58 dB (65 dB, IHF)
Frequency response 20 Hz to 15 kHz, +1 dB, -2 dB
Image rejection at 98 MHz 40 dB
IF rejection at 98 MHz 70 dB
Stereo separation (1 kHz) 40 dB
Antenna terminal 75 Ω (unbalanced)
g AM TUNER SECTION
Frequency range 522 kHz to 1611 kHz (9 kHz steps)
530 kHz to 1620 kHz (10 kHz steps)
Sensitivity 500 µV/m
Selectivity (at 999 kHz) 30 dB
g SPEAKER SECTION
Front and surround speakers (SC-HT40: SB-PF41, SB-PS41)
Type 1 Way, 1 Speaker, Bass-ref.
Speaker unit
Full range 6.5 cm cone type x 1, 4 Ω
Input power (IEC) 90 W (Max)
Output sound pressure level 76 dB/W (1.0 m)
Frequency range 110 Hz to 22 kHz (-16 dB)
120 Hz to 21 kHz (-10 dB)
Dimensions (W x H x D) 92 mm x 135 mm x 95.4 mm
Mass [SB-PF41]: 0.65 k g
[SB-PS41]: 0.7 k g
Front speaker (SC-HT60: SB-FS61)
Type 2 Way, 2 Speaker, Bass-ref.
Speaker unit
Full range 6.5 cm cone type x 1, 4 Ω
Tweeter 6 cm cone type x 1, 4 Ω
Input power (IEC) 90 W (Max)
Output sound pressure level 82 dB/W (1.0m)
Frequency range 85 Hz to 45 kHz (-16 dB)
100 Hz to 40 kHz (-10 dB)
Dimensions (W x H x D) 250 mm x 1125 mm x 234 mm
Mass 3.6 k g
Surround speaker (SC-HT60: SB-FS62)
Type 1 Way, 1 Speaker, Bass-ref.
Speaker unit
Full range 6.5 cm cone type x 1, 4 Ω
Input power (IEC) 90 W (Max)
Output sound pressure level 80 dB/W (1.0m)
Frequency range 85 Hz to 45 kHz (-16 dB)
95 Hz to 40 kHz (-10 dB)
Dimensions (W x H x D) 250 mm x 1125 mm x 234 mm
Mass 3.6 k g
Center speaker (SC-HT40: SB-PC40)
Type 1 Way, 2 Speaker, Bass-ref.
Speaker unit
Full range 6.5 cm cone type x 2, 6 Ω
Input power (IEC) 220 W (Max)
Output sound pressure level 82 dB/W (1.0 m)
Frequency range 110 Hz to 22 kHz (-16 dB)
120 Hz to 20 kHz (-10 dB)
Dimensions (W x H x D) 270 mm x 92 mm x 95.4 mm
Mass 1.3 k g
Center speaker (SC-HT60: SB-PC41)
Type 1 Way, 2 Speaker, Bass-ref.
Speaker unit
Full range 6.5 cm cone type x 2, 6 Ω
Input power (IEC) 220 W (Max)
Output sound pressure level 85 dB/W (1.0 m)
Frequency range 95 Hz to 40 kHz (-16 dB)
110 Hz to 36 kHz (-10 dB)
Dimensions (W x H x D) 270 mm x 92 mm x 95.4 mm
Mass 1.2 k g
Passive subwoofer (SB-W40)
Type 1 Way, 1 Speaker, Bass-ref .
Speaker unit (Woofer) 16 cm cone type, 6 Ω
Input power (IEC) 220 W (Max)
Output sound pressure level 78 dB/W (1.0 m)
Frequency range 31 Hz to 500 Hz (-16 dB)
38 Hz to 400 Hz (-10 dB)
Dimensions (W x H x D) 182 mm x 392 mm x 266 mm
Mass 3.7 k g
g GENERAL
Power supply AC 230 to 240 V, 50 Hz
Power consumption 120 W
Dimensions (W x H x D) 430 mm x 105 mm x 385 mm
Mass 3.8 k g
Power consumption in standby mode: 1 W
Notes:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Digital input OPTICAL 2
COAXIAL 1
