6
Connecting the AC Power
1. Connect the power cord to the AC socket. (See Fig. 1-6)
2. Connect the power cord to an AC power source.
Figure 1-6
Connecting the Audio Cable
1. Connect the audio cable to the "LINE OUT " jack on your PC's
audio card or to the front panel's “AUDIO OUT” jack of your CD
ROM drive. (See Fig. 1-7)
2. Connect the other end of the audio cable to the LCD Monitor's
"LINE IN" jack.
Figure 1-7
Power Management System
This LCD Monitor complies with the VESA DPMS (version 1.0) Power Management guidelines. The
VESA DPMS provides four power saving modes through detecting a horizontal or vertical sync. signal.
When the LCD Monitor is in power saving mode, the monitor screen will be blank and the power LED
indicator will light yellow.
