The bayonet-type mount ensures quick, easy and secure filter
cartridge replacement.
Preparing for use
Before installation
The screw thread of the tap is sharp.
Before you install the water purifier, make sure all tap-mounting
adapters you require are present.
The tap must have a diameter of 13mm-25mm.
Determine what type of tap you have and select the appropriate
adapter.
The adapters supplied make the water purifier suitable for almost
any kitchen tap. However, the water purifier may not fit some
uncommon types of taps.
The tap water pressure has to be between 0.7kgf/cm² (7 metres of
water column/70kPa) and 3.5kgf/cm² (35 metres of water column/
350kPa). If you use the water purifier at a water pressure outside this
range, either the filtered water flow will be extremely low or the
water purifier will get damaged.
installation a-type adapter
For taps with a round spout with a diameter of 16mm, 17.5mm or
19mm (Fig. 2).
1 Remove the attachment nut and the adapter from the water
purifier housing (Fig. 3).
Pass the attachment nut over the tap spout (Fig. 4).
Place the matching adapter (A-type) over the tip of the spout. The
16mm adapter is packed with the water purifier. Replace it with
the 17.5mm adapter or 19mm adapter to fit the diameter of your
tap (Fig. 5).
Screw the attachment nut firmly onto the water purifier
housing (Fig. 6).
-
-
-
-
-
-
-
