Technical Specifications
LCD panel
• Type TFT LCD
• Screen size 15 inch / 38.1 cm
• Pixel pitch 0.297 x 0.297mm
• LCD panel type 1024 x 768 pixels
R.G.B vertical stripe
Anti-glare polarizer, hard coated
• Effective viewing area 304.1 x 228.1mm
• Display colors 16.7M colors
Scanning
• Vertical refresh rate 56~76 Hz
• Horizontal frequency 30~61 KHz
Video
• Video dot rate 80 MHz
• Input impedance
- video 75 ohm
- Sync 2K ohm
• Input signal levels 0.7 Vpp
• Sync input signal Separate sync
Composite sync
Sync on green
• Sync polarities Positive and negative
• Video interface Analog (D-Sub) input
Optical characteristics
• Contrast ratio 400 (typ.)
• Brightness 250 cd/m 2 (typ.)
• Peak contrast angle 6 o'clock
• White chromaticity x: 0.283 y: 0.297 (at 9300°K)
x: 0.313 y: 0.329 (at 6500°K)
• Viewing angle Upper
≥
50°(typ.)
(C/R >5) Lower
≥
60°(typ.)
Left
≥
75°(typ.)
Right
≥
75°(typ.)
• Response time
≤
25 ms (typ.)
Resolution & preset modes
• Maximum 1024x768 at 75Hz
• Recommended 1024x768 at 60Hz
• 15 user definable modes
• 14 factory preset modes
H.freq (KHz) V.freq (Hz)
640 x 350 31.5 70
720 x 400 31.5 70
640 x 480 31.5 60
640 x 480 35.0 67
640 x 480 37.8 73
640 x 480 37.5 75
800 x 600 35.2 56
800 x 600 37.9 60
800 x 600 48.0 72
800 x 600 46.9 75
832 x 624 49.7 75
1024 x 768 48.4 60
1024 x 768 56.5 70
1024 x 768 60.0 75
(Interlace mode is not applicable)
Plug and play compatibility
• Display data channel DDC 2B (VESA)
• Microsoft® Windows® 95/98/ Me & 2000/ XP compatible
Power management
Complies with EPA Energy Star and NUTEK specifications
• Typical operation
18W (typical)
• Sleep mode 1W
Low-emission characteristics
• Complies with MPR-II and TCO 2003 specifications
Monitor controls and functions
• Side Power on/off - Tact Switch
OK
- Tact Switch
Auto - Tact Switch
Up/Down - Tact Switch
(Brightness)
Left / Right
- Tact Switch
• LED indicator Green power on
Amber stand by/sleep mode
Flashing Green new mode
Connections and cables
• Connections on monitor body
- Video 15-pin D-sub (analog)connector
- DC output 12V, 6.5mm DC connector
- Power IEC/CEE-22 type male power inlet
• Cables D-Sub video cable, Power cable
Regulatory approvals
• TÜV/GS,TÜV-Ergo
• FCC-B, UL, CSA
• SEMKO
• MPR-II Low Emission
• CE Mark
• NUTEK, Energy Star
• TCO 2003
Physical specifications
• Dim. incl. base (WxHxD) 360 x 358 x 177 mm (incl. pedestal)
• Dim. excl. base (WxHxD)360 x 294 x 55 mm
• Tilt
-5°~25°
• Net Weight 3.0 Kg
• Gross Weight 4.3 Kg
• Power supply 100 – 240 VAC, 50/60 Hz
• Power consumption 18 W* (typ.)
• Temperature (operating) +5°C to +40°C
• Temperature (storage)
-20°C to +60°C
• Relative humidity 20% to 80%
• System MTBF 50K hrs (excluding CCFL 30K hrs)
* Resolution 1024x 768, standard size, contrast max., brightness
50%, 9300°K, full white pattern, without Audio/USB.
We recommend using 1024 x 768 at 60Hz non-interlaced mode
for the best picture quality
As an Energy Star partner, Philips has determined that this
product meets the Energy Star guidelines for energy efficiency.
Microsoft and Windows are registered trademarks of Microsoft
Corporation
All data subject to change without notice
Release date: June 2003
www.philips.com
15" TFT LCD XGA monitor
150C
4FS
150C
4FS
