Panasonic KW4S User Manual
Page 3
Shrink-
wrapping
machine
1
2
Using RS485 (reduced wiring with two twisted pair cables), up to 31 Eco-POWER METERs can be connected.
Dedicated CT
Pulse output
Data from each machine is
collected using the Eco-POWER
METER dedicated data collection
software (AKW4805) and then
saved as a CSV file.
Using spreadsheet software such as Excel, data
can be freely edited (turned into graphs) and
saved. Daily and monthly reports can be
created.
1
. Standalone measurement
2
. Data management with PLC
3
. Data management with computer
(Using data collection software)
4
. Gathering data with PLC
5
. Managing data
with Web Datalogger Unit
MEWTOCOL
Always on the lookout for wasted electricity, Eco-POWER METER is
there to assist in the energy-saving activities of all customers.
Eco-POWER METER
Gathering power consumption data from each manufacturing machine
Automatic gathering of electrical power
3
Example
Configuration Examples
(Alone and as system)
