UNASSEMBLED PARTS

Mower

Gauge Wheels

(4) Washers 3/8 x 3/4 x 14 Ga.

(4) Wheels

(4) Adjusting
Bars

(4) Retainer Springs
(double loop)

(4) Clevis Pins

(4) Locknuts 3/8-16

(4) Shoulder

Bolts

Nose Roller

(2) Hex Bolts

5/16-18 x 1

(2) Locknuts

5/16-18

Steering Wheel

(1) Knob

(1) Washer
17/32 x 1-3/16 x 12 Gauge

Seat

Steering

Wheel Insert

Steering

Wheel Adapter

Steering Sleeve

Steering Sleeve

Extension

(2) Keys

Slope Sheet

Keys

(1) Front Plate
Assembly

(5) Retainer Springs

(double loop)

(2) Retainer Springs

(single loop)

(2) Flanged
Pins

Nose Roller
Brackets

Rod

Retainer Spring
