DVD-116 Operating Instructions
- 7 -
7) Audio Output
connector for analog audio output, uses a Modex 70553 connector
Select the appropriate cable from the following chart:
Pin Name Function
1 L Left channel audio output
2 G Ground
3 G Ground
4 R Right channel audio output
8) Device Configuration Jumper
set this jumper switch to select the drive use mode supporting the computer
(
jumpered = ON; no jumper = OFF)
Pin Name Function
1 MA* 1 on Drive set to Master mode
2 SL on Drive set to Slave mode
3 CS on Drive set to Cable Select mode
4 Reserved
5 Reserved
9) Host IDE Interface
40-pin I/O connector in accordance with ATA specifications
10) DC Input
power supply input for DC +5 V and +12 V
Pin Name Function
1 +12 Power supply input for DC +12 V
2 G Ground
3 G Ground
4 +5 Power supply input for DC +5 V
4.3 Region Code Information
The maximum number of times the Region Code may be changed is five (5),
including the initial setting. The fifth change becomes PERMANENT until the unit
is serviced and the counter is reset to 1.
Note: Region Codes are part of the DVD Standard, however, Region Codes on DVD
discs are optional. DVD discs with no specified Region Code may be played on any
player.
