Table 2. Scanner YELLOW LED Functions
Table 3. Scanner BEEPER Functions
LED
INDICATION
DURATION
COMMENT
Laser on
indication
On Steady
The yellow LED illumi-
nates whenever the
laser is on.
SPEAKER
INDICATION
DURATION
COMMENT
Scanner Not
Currently
Linked
Six beeps consisting of
20 ms on, 20 ms off
Indicates a bar code
was read before the
scanner was linked to
a Base Station.
Good Read
Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Three programmable
functions are avail-
able. This indicates a
bar code has been
read and decoded.
Partial Read
Bip
20 ms on
A very short beep
("bip") is sounded
when one bar code of
a two-bar code pair
has been successfully
decoded.
Base Sta-
tion
Acknowl-
edgement
Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Indicates a successful
bar code transmission
to the host (config-
urable), a successful
change of channel, or
a successful transmis-
sion of a new configu-
ration to the host.
