15 inch LCD Monitor
15 inch LCD Monitor
satisfies display requirements of
demanding users
satisfies display requirements of
demanding users
Outstanding front of screen performance
• Zero Bright Dot™ eliminates LCD bright dot defects
• XGA 1024x768 resolution for sharper display
• Dual Input accepts both analog VGA and digital DVI signals
• sRGB ensures color matching between display and printouts
Maximum comfort for maximum productivity
• Audio speakers built into a display device without clutter
• Screen height adjustable for ideal viewing angle
• Screen tilt and swivel adjustment for ideal viewing angle
• Cable management for a tidy work space
Best total cost of ownership solution
• SmartManage manages display devices remotely
• Lower power consumption than industry average
Great convenience
• Embedded power supply eliminates external power adaptors
150B5CS
Look to the Philips 150B5 to save space and money: Great, reliable display, productivity enhancing
ergonomics plus SmartManage for remote, LAN-based monitor management and low power consumption
make the Philips 150B5 the right business.
Picture/ Display
Commercial Specifications
•
LCD Panel Type
1024 x 768 pixels,
Anti-glare
Polarizer,
RGB Vertical Stripe
•
Panel Size
15"/ 38 cm
•
Effective Viewing Area
304.1 x 228.1 mm
•
Pixel Pitch
0.297 x 0.297 mm
•
Brightness (nits)
250
•
Contrast Ratio
400:1
•
Display Colors
16 M
•
Viewing Angle (C/R > 5)
- Horizontal : 160°
- Vertical : 140°
• Response Time
16 ms
• White Chromaticity, 6500º K x = 0.313 / y = 0.329
• White Chromaticity, 9300º K x = 0.283 / y = 0.297
• Maximum Resolution
1024 x 768 @ 75Hz
• Recommended Resolution
1024 x 768 @ 60Hz
• Factory Preset Modes
14 modes
• User Definable Modes
16 modes
• Horizontal Scanning Frequency 30 - 61 KHz
• Refresh Rate (V)
56 - 76 Hz
• sRGB
Yes
Connectivity
• Signal Input
Analog (VGA), DVI-D,
PC Audio in
• I/O interface on pad
Headphone Jack
Convenience
• Built-in Audio
1.5 W RMS x 2 Stereo
Speakers
• Convenience Enhancements
On-screen Display,
SmartManage
• Monitor Controls
Auto, Brightness control,
Left/Right, Menu (OK),
Power On/Off, Up/Down,
Volume
control
• OSD Languages
English, French, German,
Italian, Simplified Chinese,
Spanish
• Other Convenience Features
Kensington Lock
• Plug & Play Compatibility
DDC/CI, sRGB,
Windows
98/ME/2000/XP
• Regulatory Approvals
CE Mark, E2000, EMC,
FCC-B, UL, CSA, NUTEK,
Energy Star, SEMKO,
TCO'03, TÜV/GS, TÜV-Ergo
• Swivel
+/- 125°
• Tilt
-5° to 25°
• VESA Mount
100 mm x 100 mm
Accessories
• User Manual
Yes
• Included Accessories
AC Power Cord, Audio
Cable, VGA Cable
Product Highlights
Dimensions
• Depth (with base)
209 mm
• Height (with base)
322 mm
• Width (with base)
342 mm
• Height Adjustment Range
70 mm
• MTBF
50,000 (excl. CCFL
40,000)
hrs
• Relative Humidity
20 % - 80 %
• Temperature Range (Operation) 5°C to 40°C
• Temperature Range (Storage)
-20°C to 60°C
• Weight
4.2 kg
Power
• Complies With
E2000, Energy Star,
NUTEK
• Consumption
19 W (Typical)
• Off Mode
< 1 W
• Power LED Indicator
Operation, Green;
Stand
by/Sleep,
Amber
• Power Supply
Built-in
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
As an Energy Star partner, Philips has determined that
this product meets the Energy Star guidelines for
energy efficiency.
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: December 2004, v.2
www.philips.com
Zero Bright Dot™
Bright dots are defects in a LCD panel once thought to be an
inevitable part of the manufacturing process. With Zero Bright
Dot™, Philips monitors are guaranteed without dot defects.
XGA, 1024 x 768 resolution
For graphics monitors, the screen resolution signifies the number
of dots (pixels) on the entire screen. For example, a 1024-by-768
pixel screen is capable of displaying 1024 distinct dots on each
of 768 lines, or about 786 thousand pixels. XGA provides
resolutions of 640 by 480 or 1024 by 768 pixels. In addition,
XGA allows monitors to be non-interlaced. This ensures a better
display performance and accurate color display effect.
Dual Input
Connectors to accommodate input of both analog VGA and digital
DVI signals.
sRGB ready
Calibrated RGB that is optimized for the vast majority of computer
peripherals, monitors, operating systems and browsers, allowing
accurate color mapping with very little data overhead.
Built-in Speakers
Audio speakers built into a display device.
Adjustable height
The ability to set your monitor to the most pleasurable viewing
height. Height adjustment makes computer work more comfortable
and reduces fatigue or eyestrain, even when you spend long hours
working on the computer. It makes you more productive.
Screen tilt and swivel
Movement of a screen to attain the ideal viewing angle.
Cable management
A system for organizing cables and wires required for the operation
of a display device to have a tidy work space.
SmartManage
A system for monitoring, managing and checking status of display
devices as well as delivering remote support to users who experience
difficulties all accomplished over a LAN.
Lower power consumption
Reduction of the electrical power required to operate a device.
Embedded power supply
A power adaptor built into the body of a display device that
replaces a bulky external power adaptor.
