Device Overview
Primo · Voice overview
‚
Handset
ƒ
Paper tray
„
Document feeder (writing facing up)
…
Panel with display
†
)-Socket—Connection socket for the telephone
handset
‡
EXT-Socket—Connection socket for additional de-
vices
ˆ
LINE-Socket—Connection socket for telephone cable
PPF 63x, PPF 67x
Internal Description
‚
Scanner glass
ƒ
Rollers of the automatic document feeder
„
Rests of the intake rollers
…
Document guide / scanner film
†
Cover for scanner and automatic document feeder
‡
Toothed wheel for tightening the ink film
ˆ
Ink film roll in the rear ink film compartment
‰
Ink film roll in the front ink film compartment
Š
Slot for the Plug’n’Print card
‹
Locks for the cover of the scanner and automatic doc-
ument feeder
