SPECIFICATIONS
GENERAL
CCD Sensor:
1/3-inch interline transfer
Picture Elements
CC3701H-2:
768 (H) x 494 (V)
CC3701H-2X:
752 (H) x 582 (V)
Sensing Area:
6 mm diagonally
Synchronize System:
INT/AC line lock
Horizontal Resolution
CC3701H-2:
480 TV lines
CC3701H-2X:
480 TV lines
Iris Control:
Electronic/passive
Minimum Illumination:
0.4 lux at f1.2, 30 IRE
ESC:
1/60-1/100,000 second
Signal-to-Noise Ratio:
52 dB (AGC off)
Gain Control:
Automatic
Vertical Phase:
Adjustable 0° ± 120°
Backlight Compensation:
Selectable by DIP switch setting
Scanning System
CC3701H-2:
525 lines, 2:1 interlace
CC3701H-2X:
625 lines, 2:1 interlace
Signal Processing:
DSP with microprocessor control
Auto Iris Lens Type:
DC/video control, selectable by DIP switch position
Video Output:
1 Vp-p, 75 ohms
1.2 Vp-p for long-line transmission
ELECTRICAL
Power Requirements
24 VAC:
18-30 VAC
12 VDC:
10-36 VDC
Power Consumption
3.3 watts maximum
5.4 vA maximum
Power Connector
2-pin terminal strip, push-in type with screw fastener
Video Connector
BNC
Lens Jack
4-pin connector (miniature square)
MECHANICAL
Lens Mount
C/CS mount (adjustable)
Camera Mount
Use 1/4-20 screw, top or bottom of camera housing
ENVIRONMENTAL
Operating Temperature:
14° to 122°F (-10° to 50°C)
Storage Temperature:
14° to 158°F (-10° to 70°C)
PHYSICAL
Dimensions:
2.45 (W) x 2.65 (H) x 4.25 (D) inches (6.22 x 6.73 x 10.79 cm)
Weight (without lens):
0.77 lb (0.35 kg)
(Design and product specifications subject to change without notice.)
