Planar PT1550MX - Manual (Page 19)

17
On-Screen Display Menus
Main OSD Menu:
ITEM SUB MENU CONTENT
Contrast 0-100 Adjusts the maximum luminance level of the monitor
Brightness 0-100 Adjusts the backlight of the monitor
Auto Adjust NO/YES Automatically adjusts the sys tem clock
Left/Right 0-100
The screen is moved horizontally right and left (1 pixel
pitch increment)
Down/Up 0-100
The screen is moved vertically up and down (1 line
increment)
Horizontal size 0-100
The ratio of dividing frequency of the dot clock is
adjusted.
Fine tune 0-100 The phase of the dot clock is adjusted.
OSD Left/Right 0-100 Adjusts the OSD menu sc reen position left or right.
OSD Up/Down 0-100 Adjusts the OSD menu sc reen position up or down
OSD Time out 0-100 Adjusts the amount of the OSD menu is displayed
OSD Language
Select the language used for the OSD menu from
among English, French, Japanese, Deutsch, Spanish,
Italian, Traditional Chinese, and Simplified Chinese
Volume 0-100 Controls the sound volume.
Mute No/Yes Disables the sound immediately.
