Operations
Push the power button (Indication E) on the front of the LCD monitor to turn it on. When the
power light (Indication F) turns green, the LCD is ready to use. Push the power switch button
to turn off.
Function Keys
B
A
C
D
E
F
A. Menu
1. Press this button to turn on/off the OSD (On Screen Display) main
menu.
2. Press this button to activate selected items.
B. [
−
]
1. To scroll down the menu.
2. To decrease the value of selected item.
C. [
+
]
1. To scroll up the menu.
2. To increase the value of selected item.
D. Auto
Press this button to activate ”AUTO SYNC”, ”AUTO-CONTRAST” and
“BRIGHTNESS”.
E. Power switch Press this button to turn on/off the monitor.
F. Power LED
When the light is green, the power is on and orange is when the power is
active off.
Hot Keys
Auto:
Press the [Auto] button to activate Auto-Sync, Auto-Contrast and Brightness
under any circumstances.
