Page 6
6
Scroll Air Compressors Tankmount/Basemount
Electrical Wiring Diagram - Simplex
Figure 4 - 3-5 HP Basemount/Simplex Single-Phase 208/230 Volts
Field furnished
power supply
❉
Disconnect
Red
Black
Motor
Red
Red
Pressure
electric
switch
L1
L2
T1
T2
Open
Red
Black
Red
Red
Red
Red
Black
Red
Blank
❉
Main disconnect and branch circuit protection to be installed by a
qualified electrician in accordance with national and local codes.
