Page 4 Installation Instructions
Parts List
NOTE: This mount is shipped with all installation hardware and components. Make sure that none
of these parts are missing and/ or damaged before beginning installation. If there are parts
missing and/or damaged, please stop and contact Premier Mounts - (800) 368-9700.
Installation Tools
Phillips Head Screw Driver Portable Drill
Soft Material/ Blanket Pencil
5/16” Drill Bit (for wedge anchors) Level
Tape Measure Ratchet with 14mm Drive Socket
Stud Finder (Sold Separately) M3 Allen Wrench (Supplied)
Mounting Backplate (Qty 1)
#14 x 2”Wood
Screws (Qty 4) M4 x 10mm Phillips
Head Screws (Qty 4)
Tilt/Pivot Mount (Qty 1)
PTM-B
1/4” x 1-1/2” Wedge Anchors
(Qty 4). These are used only
for concrete applications.
M6 x 35mm Set Screw
(Qty 1)
UFP-200 Plate (Qty 1)
M4 x 5mm Phillips
Screws (Qty 4)
M4 x 10mm Flat Head
Phillips Screws (Qty 6)
