Pride Mobility 1420 User Manual
Page 17
17
Quantum Jazzy 1400 Series Rev D May04
www.pridemobility.com
I V. T H E Q U A N T U M J A Z Z Y 1 4 0 0 S E R I E S
BATTERY
REAR SEAT TOWER
REAR SEAT TOWER
ELECTRONICS TRAY
FRONT SEAT TOWER
FRONT SEAT TOWER
Figure 3. The Quantum Jazzy 1420 Power Base (Shroud Removed. 1400 is similar.)
FREEWHEEL LEVER
(UNDERNEATH
ELECTRONICS TRAY)
BATTERY
MAIN CIRCUIT
BREAKER
AMMETER
CONTROLLER CONNECTOR
(REMOTE PLUS SHOWN)
ONBOARD CHARGER AC
POWER CORD
Figure 4. The Quantum Jazzy 1420 Electronics Tray (1400 is identical.)
CHARGER FUSE
POWER MODULE
ONBOARD BATTERY
CHARGER (UNDERNEATH
ELECTRONICS TRAY)
