SBC RU940
Standard product information
• Power supply 4 x LR6 (included)
• Battery lifetime 6 months
• Processor Motorola DragonBall MC68328
• SRAM 512 Kb (0.5Mb)
• Flash memory 2048 Kb (2Mb)
• PC port RS232 Serial port (3 wire connector)
• Transmission type IR universal
• Transmission system Modulated
• Effective IR range > 15 meters
• Transmission angle 130 deg.
• Transmission LEDs 5
• No. direct access buttons 8
• Audio Piëzo speaker with adjustable volume
• Weight 250g, with batteries
• Dimensions (mm) 138 x 92 x 38 (L x W x H)
• Warranty 1 year European warranty
LCD information
• Dimension (mm)
77 x 58
• Resolution 320 x 240, 0.24mm pitch
• Refresh rate 70 Hz
• Color scales 4 gray levels
• Dynamic LCD input Finger or blunt object
• EL backlighting Yes
Installation
• Pre-installed
RC5, RC6 (Philips & Marantz ready)
• Learnable yes
• No. of devices Unlimited (within memory)
• No. of learnable codes Unlimited (within memory)
Features
• Direct-access buttons
Mute
Channel Up/Down
Volume Up/Down
Right/Left Configuration buttons
Backlight button
• Customisable User Interface
• manual or via PC Yes
• Software upgradeable Yes
• Macro functionality Yes, Unlimited (within memory)
• Timer functionality Yes, Unlimited (within memory)
• Automatic backlighting Yes
• LCD Contrast adjustment Yes
• Auto power on/off Yes
Packaging
Pronto (SBC RU940/00) Docking station (SBC RU941/00)
• Type Carton box Carton box
• Dimensions (mm) 196 x 241 x 54 196 x 241 x 79
• Languages GB, D, F, NL GB, D, F, NL
• Languages IFU GB, D, F, NL GB, D, F, NL, S, FIN, I
• 12NC 9082 100 00517 9082 100 00518
• EAN code 87 10101 67892 4 87 10101 67893 1
Inner carton NONE
Outer carton
• Contents
5
• Dimensions (mm) 305 x 260 x 210 350 x 255 x 210
• Weight (Kg) 3,5 3,5
• EAN code 87 10101 87280 3 87 10101 87281 0
Pronto is a universal learning remote control that combines
elegance, flexibility and ease of use. It combines a large
touchscreen display with an intuitive user interface and direct-
access buttons to conveniently provide home entertainment
control.
Dynamic, Interactive, user interface
The intuitive graphical user interface is easy to understand. The
dynamic display uses familiar icons and sliding menus, which allow
for quick and easy executions of commands. Pronto allows
maximum flexibility for even the most sophisticated audio/video
products
Pronto is as unique as you are!
Pronto’s unparalleled design combines the benefits of a dynamic,
digital user interface with direct access buttons. It’s easy to add,
delete, and label new buttons or menus. This allows maximum
customisation according to individual needs and tastes.
Universal, learnable and expandable
Pronto can control almost all infrared (IR) receiving devices. It
comes pre-programmed with RC5 and RC6 commands for Philips
and Marantz components. Pronto can be ‘taught’ to control any
other IR controlled product, regardless of brand.
Unlimited macro functionality and timer facility
Allows combinations of commands to be created and controlled
under one macro button. The Pronto’s timer can programme your
VCR to record and play at any time. Perfect for putting you in
total control of your home entertainment products.
Software upgradeable
Thanks to ProntoEdit software, which is freely available on the
Internet, and which enables configurations to be duplicated, new
IR codes to be stored, and graphics and templates to be added.
Pronto recharge docking station
Optional recharging system that’s ideal for table-top operation
while charging Pronto, and for storing Pronto when not being
used.
SBC RU941 Pronto recharge docking station
(optional)
• Keeps Pronto charged when not in use
• Allows Pronto to be used even while docked
• Includes NiMH rechargeable battery, power adaptor and
docking station
http://www.pronto.philips.com
