11
Front Panel
The buttons and indicators on the Front Panel of your SH-DT510 are
described in the following picture and table:
Rear Panel
The rear panel carries connectors for attaching VHF/UHF antenna and other
home entertainment equipment. To ensure highest quality video output, it
is recommended to use (in order of preference) HDMI, Component Video,
S-Video, Composite Video.
STANDBY/ON MENU/ ENTER RETURN
DIGITAL HIGH DEFINITION TUNER SH-DT510
LED Display Standby / On
LED Indicators
SERVICE
ONLY AUDIO OUT
L
R OPTICAL
Y
P B
P R
COAXIAL
HDMI OUT VIDEO OUT
COMPONENT
VIDEO S- VIDEO
VIDEO RF IN
RF OUT
ANT
AC IN
Composite
Video Out
Component
Video Out
S-Video
RF In
VHF/UHF
Antenna
HDMI
Data port
AC Power
Digital
Audio Out
Audio
Out RF Out
