Philips PET7432/05 User Manual

Quick start guide, Prepare (for in-car use), Enjoy

background image

2 Connect the AC adaptor cable to the DC

IN Jack on the main unit and the power
outlet.

3 Switch on the TV and set to the correct

video-in channel.
➜ You can consult the owner's manual of

your TV. (If your TV does not have Audio
and Video inputs, you will need to
purchase a RF modulator. Please consult
your dealer.)

1 Attach the main unit and the second screen

to the back of the front seat headrests.

2 Connect the supplied AV cable to the AV

OUT jack on the main unit and the AV IN
jack on the second screen.

3 Connect the supplied car adaptor cable to

the DC IN jacks on the main unit and the
second screen, and to the car cigarette
lighter socket.

Prepare (for in-car use)

1

Quick start guide

Philips Portable DVD Player PET7432

1 Slide the ON/OFF switch to ON to switch

on the main unit.

2 Slide OPEN

2 on the main unit.

3 Remove the protective card (if any) and load

a disc with the label side facing up.

4 Close the disc compartment.

➜ Playback will start automatically. If not,

press

2;/OK.

5 To stop playback, press

9.

2

Enjoy

Note:
During play, you can:
– Press OPTION to select some play options:

audio, subtitle, repeat, and time display.

– Press BRIGHTNESS on the main unit or

rotate BRIGHTNESS -/+ on the second
screen to adjust brightness of screen to match
lighting conditions.

1

Prepare (for domestic use)

Connect additional equipment (TV for
example)

1 Connect the AV OUT socket on the main

unit to the video and audio sockets on a TV
as shown directly.

Printed in China

WK0911

TV

Main unit

Red

Yellow

Not supplied

Second screen

AV cable

Car adaptor

cable

Cigarette

lighter

White

Note:
– This portable DVD player is designed with a

built-in lithium battery to supply power to the
player when you are on travel(charging of the
DVD player only possible in the power-off
mode).

PET7432-Eng_QSG.qxd 3/17/09 11:34 Page 1
