15 inch CRT Monitor 15 inch CRT Monitor
great CRT value and quality plus
lead-free design great CRT value and quality plus
lead-free design
Better front of screen experience
• Flat square tube reduces distortion and reflection
• SVGA 800 x 600 resolution for sharper display
Great convenience
• Compatibility with PC and Mac platforms
• Quick and easy to personalize On-Screen-Display control
• Easy, user friendly plug-and-play installation
Green design
• Lead-free design safeguards our environment
105S68
Great quality and value merge in the 105S6 CRT monitor. Easy to install, easy to personalize and
compatible with both PC and Mac computers, this affordable display features lead-free design that
safeguards our environment.
Commercial Specifications
Flat square tube
A tube designed to reduce distortion and reflection.
SVGA, 800 x 600 resolution
For graphics monitors, the screen resolution signifies the number
of dots (pixels) on the entire screen. For example, a 800-by-600
pixel screen is capable of displaying 800 distinct dots on each of
600 lines, or about 600 thousand pixels. SVGA provides
resolutions of 640 by 480 or 800 by 600 pixels.
Two-platform compatibility
The ability to work with a variety of platforms; Philips monitors
are compatible to connect with PC by employing a VGA connection
and connect with Macintosh.
OSD On-Screen-Display control
An on-screen panel for adjusting a monitor. The OSD is used for
contrast, brightness, horizontal, vertical positioning and other
monitor adjustments.
Easy plug-and-play
Plug-and-play is a perpheral connectivity standard. A plug and play
display device can be connected to a PC and operate without
requiring user intervention to adjust complicated settings.
Lead-free
Lead-free display products are designed and produced in
compliance with strict European Community Restriction of
Hazardous Substances (RoHS) standards that restrict lead and
other toxic substances that can harm health and the environment.
Product Highlights
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: January 2005, v.2
www.philips.com
Picture/Display
• Display screen type Flat square tube
• Panel size 15"/ 36 cm
• Phosphor P22
• Recommended display area 270 x 202 mm
(10.6" x 8.0")
• Dot pitch 0.28 mm
• Horizontal dot pitch 0.24 mm
• White chromaticity, 6500º K x = 0.313 / y = 0.329
• White chromaticity, 9300º K x = 0.283 / y = 0.297
• Max. resolution 1024 x 768 @ 60 Hz
• Recommended resolution 800 x 600 @ 85 Hz
• Factory preset modes 6 modes:
640 x 480 @ 60 Hz, 640 x 480 @ 75 Hz,
720 x 400 @ 70 Hz, 800 x 600 @ 75 Hz,
800 x 600 @ 85 Hz, 1024 x 768 @ 60 Hz
•
Factory preload modes 9 modes
• Video dot rate 75 MHz
• Horizontal scanning frequency 30 - 54 KHz
• Vertical scanning frequency 50 - 120 Hz
• Recommended refresh rate 85 Hz
• Screen enhancements Anti-glare Polarizer,
Anti-Reflection, Anti-Static
Connectivity
• Cables D-sub Video cable,
Power cord
• Sync input impedance (ohm) 4.7 k
• Video input impedance (ohm) 75
• Video input signal levels
0.7 Vpp
• Video sync input signal Separate sync
• Video sync polarities Positive and Negative
• Cable connection AC Power in
Convenience
• Convenience enhancements Menu languages,
On-screen display
• Monitor controls Brightness control,
Contrast control,
Left/Right, Menu,
Power On/Off
• OSD languages English, French, German,
Italian, Spanish, Portuguese,
Russian
• Plug & Play compatibility DDC 2B
Windows 98/ME/2000/XP
• Regulatory approvals FDA, EZU, MEEI, PCBC,
GOST, SEMKO, CE Mark,
TÜV/GS, TÜV Ergo, FCC-B,
UL, CSA, NUTEK
• Swivel +/- 90°
• Tilt -5° to 15°
Accessories
• Included accessories AC Power cord
• User manual Yes
Dimensions
• Depth (with base) 387 mm
• Height (with base) 362 mm
• Width (with base) 360 mm
• Temperature range (operation) 0°C to 40°C
• Temperature range (storage) -25°C to 65°C
• Weight 11.5 kg
Power
• Complies with NUTEK
• Consumption 62 W (Typical)
• Off mode 5 W
• Power LED indicator Off, amber;
Operation, green
• Power supply Built-in
