Polaroid PDM-0743M - Manual (Page 39)

39
TFT screen size 7 inches (16：9)
Screen resolution 480x234
Laser Wavelength 780/650nm
Video System NTSC
Frequency Response 20Hz - 20kHz ±2.5dB
Audio Signal-to-noise Rate ≥85dB
Audio distortion + noise ≤ -70dB (1kHz)
Channel Separation ≥70dB (1kHz)
Dynamic Range ≥80dB (1kHz)
Audio Out Out Level 2V± 0.2
1.0 , Load 10k Ω
Video Out
Out Level 1V
P-P
±0.2, Load 75 Ω
Unbalanced Negative
Power AC100 ～ 240V（50/60Hz）
Dimensions 202mm x 150mm x 40mm
Weight Approximate 0.75 Kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Specifications
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
©
1992 -1997 Dolby Laboratories, Inc.
All rights reserved.
