4 TECHNICAL
15
M80 Technical Specifications:
Number of Channels Eight
Dynamic Range >120dB
Noise Floor @ Bus -90.2dBu
Noise Floor @ Main Output -96.4dBu
Noise Floor @ Channel Output, +24dB Gain -88.2dBu
Headroom +28dBu
Frequency Response +/- 0.5dB 10Hz to 60kHz
Crosstalk >82dB @ 10kHz
Channel Gain, Microphone Input +24dB to +60dB
THD + Noise, (no idss) 0.0024%
THD + Noise, (max idss) 0.035%
Input Impedance 10k Ohms
Output Impedance 51 Ohms
THD + Noise <0.02%
Bus Master Output Control -72dBu to +10dBu
Metering Full scale
Send Output Impedance 51 Ohms
Return Input Impedance 10k Ohms
Internal Operation Level +4dBu = 0dB
Input Connectors Neutrik combo jack,
Output Connectors XLR
Send Connector 1/4”, Tip Ring Sleeve
Return Connector 1/4”, Tip Ring Sleeve
Power Supply External, Toroidal Transformer,
Linear Supply
Power Requirements 100VAC to 120VAC, or
200VAC to 240VAC
Main Connection EIC receptacle
Size 2U Rack
19” X 3.5” X 7”
Weight 12 lbs.
As a commitment to constant improvement, PreSonus, Inc. reserves the right to change any
specification stated herein at any time in the future without notification.
