• Skate-seat
• Bumper bar
• Hood and cover
•
Rain cover
• Standard adapter set for car seat group 0+ "Primo
Viaggio SIP" or "Primo Viaggio tri-fix" Peg Perego.
instructions for use
MOUNTING THE WHEELS
1• Remove the protection caps from the rear
wheels. To mount the rear wheels, insert the pins
into their housings until they click into place.
2• Before fitting the front wheels, make sure that
the indicators on the fastening controls are red.
Insert the pins of the wheels in the appropriate
housing, making sure that the green lines of the
wheels match up with the green lines of the
housing. Finally, turn the fastening controls until
the indicators are green.
• IMPORTANT: Check that the wheels are
secured by pulling them.
OPENING the Skate chassis
3• To open the Skate chassis remove the locking
levers (fig. A) from the side pins and push them
up until they go back in.
4• If it is in the closed position (fig. A), rotate the
handlebar by one position (fig. B, open the two
levers outwards, position the handlebar and
close the two levers again) to avoid contact with
the centralized locking pedal (fig. C).
5• Hold the Skate chassis down with a foot and raise
the handlebar until it clicks into place.
Check that the chassis is open properly by making
sure that the front of the centralized locking pedal is
not red.( If the red part is visible, continue to pull up
the handlebar until you hear it click and the red is
no longer visible on the centralized locking pedal.
The Skate chassis can also be opened when the
Skate-seat is attached; after opening the Skate
chassis, recline the Skate-seat as needed (see
reclining the Skate seat section). IMPORTANT: Sit
the child in the Skate-seat only after opening
the Skate chassis.
CENTRALIZED BRAKE
6• To apply the brakes, push down with one foot
the bars on the rear wheels, as shown in the
figure. To release the brakes, draw the bar up.
FRONT SWIVEL WHEELS
7• To set the front wheels to swivel, lift the stopper
up, as in figure A. To set the wheels in a fixed
position, push the stopper down, as in figure
B. When they are turned around, the wheels
automatically fix into place.
REAR INFLATABLE WHEELS
8• A pump is attached to the bottom of the frame
in the rear of the stroller to inflate the rear wheels.
Pull out the cord from the top of the pump and
screw it in the figure. Unscrew the wheel valve
cap and screw the cord of the pump.
• Before using the stroller for the first time you
are advised to inflate the tires to a pressure of
25 psi/1.7 bar.
• IMPORTANT: Do not inflate the wheels too
much; max pressure is stated on the wheel.
HANDLEBAR
• The handlebar of the Skate chassis is telescopic
and the handle grip is height adjustable to 3
positions.
9• To extend the handlebar, pull up the two
handlebar extender hooks simultaneously and
place the handlebar at the height you want it.
10• To adjust in height the handle grip, open the
two levers outwards, place the handle grip in the
position you want and lock the two levers again.
BOTTLE HOLDER
11• The bottle holder can be attached to both sides
of the Skate chassis, To attach it, insert the back
of the bottle holder into the housing provided
on the Skate chassis.
BASKET
12• The basket is equipped with adjustable elastic
straps to secure the contents. Before connecting
the straps, place the elastic strings in the
suitable position.
REMOVING THE WHEELS
13• To remove the rear wheels from the Skate chassis,
pull out the pin while taking off the wheels.
14• To remove the front wheels from the Skate
chassis, turn the fixing knobs until the indicators
are red, then take off the wheels.
ATTACHING THE Skate-SEAT TO THE Skate CHASSIS
15• Before attaching the Skate-seat to the Skate
chassis, make sure both locking systems are
at the same height and rotated to the same
position.
16• To attach the seat, insert the legs of the Skate
seat into the holes in the Skate chassis until they
click into place.
• IMPORTANT: Make sure the Skate-seat is
attached properly by pulling it upwards.
• IMPORTANT: This operation is required only
if the Skate-seat is in carriage mode and
your child weighs less than 9 kg (19.8 Ibs).
RECLINABLE Skate-SEAT
17• The Skate-seat can be reclined to 3 positions
(horizontal, partially reclined and reclined) either
facing parents or the other way.
• To recline the Skate seat, pull up the handle
behind the backrest and adjust the Skate seat to
the position you want.
• Skate carriage seat: the Skate-seat must be
fully horizontal.
• Skate stroller seat: the Skate-seat can be
inclined to the 3 positions available.
