V50TYLA-DO
Item# Part Descripition Part Number
1 Log Set VL050-01A
2 Fan/Heater Assembly NFHTX186-R/VB17-000-R
3 Synchronization Motor-220Volt AC w/Terminal FE23A307
4 Cord Power H05VV-F3GX1.0 w/Terminal NFHL008-R-A
5 ON/OFF Switch VL067-01
6 Heater Control (Thermostat) VL053-02
7 Heater Control Knob NFHL012
8 Flame Generator Assembly/Firewood Glisten Paper PT/32GS370/FE33A205-01
9 Light Bulb Socket w/Wiring Assembly PE28A306-R
10 Screen EB29600
11 Top Panel EL040-01-DO
12 Side Panel (Right/Left) EL015-06-DO
13 Left Lower Panel/Right Lower Panel EL012-06
14 Door EL013-01
15 Brass Knob 224A
16 Back Panel EL019-01-B
17 Base EL018-06RA-DO
18 Upper Decorating Frame EL016-06H-O
19 Upper Decorating Wire EL011-01
20 Upper (Mid) Louver VL015-01(VL014-01)
21 Pilot Light Bulb Socket w/Wiring Assembly VL080-01
22 Base Plate ( Not shown) VL091-01-R
23 Driver Wheel 1/ Driverwheel 2(Not shown) VL005-03A
24 Switch Mount Panel ( Not shown) VL004-01F
