Step 6: Connecting the
power cord
After everything is connected
properly, plug the AC power cord
into the power outlet.
The Eco Power LED on the DVD system
and the AV subwoofer will light up.
Never make or change any connections
with the power turned on.
Helpful Hints:
– Refer to the type plate at the rear or
bottom of the product for identifi cation and
supply ratings.
FM 75
MW
FM/MW ANTENNA
TO AV SUBWOOFER
HDMI OUT
~
MAINS
R
L
Basic Connections
(continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
