M8 Nylon Locknut (78) M10 Nylon Locknut (77)
M6 Washer (81)
M8 Washer (83)
M4 Washer
(84)
M10 Washer (80)
M10 x 87mm Button Bolt (94)
M8 x 53mm Bolt (9)
M6 x 72mm Button Screw (92)
M6 x 25mm Button
Screw (17)
M6 x 15mm
Button Screw (96)
M10 x 50mm Bolt (79)
M10 x 45mm Bolt (75)
M10 x 82mm Bolt (85)
M10 x 78mm Bolt (87)
M10 x 67mm Bolt (86)
M10 x 63mm Button Bolt (90)
M10 x 58mm Button Bolt (95)
M10 x 100mm Screw (26)
M10 x 70mm Bolt Set (93)
M8 x 10mm Set
Screw (62)
M4 x 16mm Self-
tapping Screw (91)
M8 x 20mm Button
Screw (16)
M10 x 20mm
Bolt (89)
M10 x 25mm
Bolt (88)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts
may have been preassembled. If a part is not in the parts bag, check to see if it has been preassembled.
If a part is missing, call toll-free 1-888-533-1333.
