Technical Specifications
Specifications S-1EX
3-way vented box system
S-2EX
3-way vented box system
S-7EX
3-way vented box system
S-W1EX
Powered subwoofer
CP-2EX
Speaker stand for S-2EX
CP-7EX
Speaker stand for S-7EX
Enclosure:
Front-vented bass refl ex
Floor-standing type
Front-vented bass refl ex
Bookshelf type
Front-vented bass refl ex
Center speaker type
Passive radiator
Floor-standing type
— —
Speakers (Tweeter):
Speakers (Midrange):
Speakers (Bass):
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone (x2)
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone (x2)
12 in. (30 cm) Aramid cone +
12 in. (30 cm) Aramid cone
passive radiator
—
—
—
—
—
—
Frequency Range: 28 — 100,000 Hz 34 — 100,000 Hz 34 — 100,000 Hz
25 — 4,000 Hz
(Set to BYPASS)
— —
Sensitivity (2.83 V/1 m): 89.5 dB SPL 86.5 dB SPL 89.5 dB SPL — — —
Nominal Impedance: 6 Ω 6 Ω 6 Ω — — —
Maximum Power (Input) : 200 W 200 W 200 W — — —
Power output (RMS) : — — — 250W / 4 Ω (100 Hz) — —
Cross-over Frequencies :
400 Hz
2 kHz
400 Hz
2 kHz
400 Hz
2 kHz
50 — 150 Hz
(Continuously variable)
— —
Dimensions (W x H x D):
16-5/8 x 50-1/2 x 24 in.
422 x 1283 x 609 mm
11-7/16 x 22-1/4 x 16-3/4 in.
291 x 565 x 425 mm
32-5/16 x 11-7/16 x 16-3/4 in.
820 x 291 x 425 mm
16-15/16 x 18-14/16 x 16-15/16 in.
430 x 480 x 430 mm
15-3/4 x 23-3/4 x 20-3/16 in.
400 x 604 x 513 mm
(without decoupling spikes)
19-5/8 x 12-3/16 x 16-1/4 in.
498 x 310 x 412 mm
(without decoupling spikes)
Weight:
145 lbs. 8 oz.
66.0 kg
61 lbs. 12 oz.
28.0 kg
86 lbs.
39.0 kg
75 lbs. 14 oz.
34.5 kg
39 lbs. 4 oz.
17.8 kg
30 lbs. 14 oz.
14.0 kg
Power Requirements /
Consumption
— — — 120 V, 60 Hz / 56 W, 90 VA — —
Finishes:
Grille:
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
Cabinet: MDF with Real
wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
Stand: Black Plywood
(satin fi nish)
Decoupling Spikes: Silver
Stand: Black Plywood
(satin fi nish)
Decoupling Spikes: Silver
