Philips 150B1 User Manual
Page 11
3
Blue video input
11
Identical output - connected
to pin 10
4
Identical output - connected
to pin 10
12
Serial data line (SDA)
5
Self test
13
H. Sync / H+V
6
Red video ground
14
V. Sync (VCLK for DDC)
7
Green video ground
15
Data clock line (SCL)
8
Blue video ground
RETURN TO TOP OF THE PAGE
Views
Follow the links to see various views of the monitor and its components.
Front View Product Description
RETURN TO TOP OF THE PAGE
150B Product Information
file:///D|/Philips LCD/english/150B/PRODUCT/PRODUCT.HTM (5 of 5) [1/20/2001 3:06:18 PM]
