Polk Audio Lsi Series User Manual

Page 11

SURROUND AND CENTER LOUDSPEAKERS

LSi F/X*

LSi

Driver Complement

2 - 5 1/4" (13.3cm) Dynamic Balance mid/bass drivers

2 - 1" (2.5cm) Dynamic Balance Ring Radiator tweeters

1 - 1" (2.5cm) Dynamic Balance Ring Radiator tweeter

Frequency Response: Overall / -3dB Limits

40Hz - 27kHz / 52Hz - 26kHz

Impedance

compatible with 4 Ohms outputs

Recommended Amplification

20 - 200 Watts / channel

Efficiency

88dB

Available Finish

high gloss black

Shipping Weight (+/- 3 lbs/kgs)

55 lbs/pair (24.9 kg)

25 lbs/each (11.3 kg)

Dimensions

15"H x 13 1/4"W x 10"D

7"H x 21 3/4"W x 9"D

38.1cm H x 33.6cm W x 25.4cm D

17.8cm H x 55.2cm W x 22.8cm D

Features

switchable bipole/dipole, PowerPort, dual gold-plated

PowerPort, ARC Port, magnetic shielding*, dual gold-plated

5-way binding posts, bi-amp/bi-wire terminals

POWERED SUBWOOFERS

PSW1000*

Driver Complement

2 - 10" (25cm) woofers

Amplifier

400 watts into 2 Ohms

Continuous Average Power**

with <1% THD, 20 - 145Hz

Subwoofer Amp Dynamic Power

825 Watts

Port Type

slot loaded PowerPort

Frequency Response: Overall / -3dB Limits

20Hz - 160Hz / 30Hz - 125Hz

Crossover Frequency

adjustable 50Hz - 140Hz

Inputs

speaker, line level & LFE

Outputs

speaker level, pass through or 80Hz high pass filter (switchable).

Line level, high pass filter fixed at 80Hz.

Available Finish

high gloss black, ebony or cherry side panels

Shipping Weight (+/- 3 lbs/kgs)

81 lbs/ea (36.7 kg)

Dimensions

16 3/4" H x 16 7/8"W x 19 3/8"D

(Including Grille, Heat Sink, Binding Posts)

42.5cm H x 42.8cm W x 49.2cm D

Features

Auto on/off, unfiltered LFE input, PowerPort, magnetic shielding*, speaker

& low level inputs, front panel volume & crossover controls, dual gold-plated

5-way binding posts, +3 db bass boost, 1 1/2" cabinet baffles.

* Magnetically shielded components for safe placement near TVs or video monitors.
** About Power Ratings:
The Federal Trade Commission has issued new regulations regarding the power ratings of all amplifiers, including self-powered speakers. Polk Audio supports this effort to standardize
power testing methods in order to provide consumers with a “level playing field” basis for comparison. Note, however, that the FTC rating is based on the “Continuous Power” output
of the amplifier. Music and movies are rarely “continuous” but are mainly composed of short bursts of sound. For this reason we also supply a “Dynamic Power” rating that measures
the ability of the amplifier to produce power in short bursts similar to those found in music and movies. In our experience, an amplifier with higher Dynamic Power output will play louder
under most conditions regardless of the continuous power rating.

We’re fanatics when it comes to providing you useful, accurate information that can help you evaluate our products. But as we all know, we live in an imperfect world. At least some of us do.
That’s why performance specifications and product dimensions are subject to change without notice. For the most current specifications see our website, www.polkaudio.com/home.
