6
6. Remove the backing from the Adhesive Clip (98).
Press the Adhesive Clip onto the base of the Uprights
(71) in the indicated location. Press the Allen Wrench
(99) into the Adhesive Clip.
71 99 98
6
7. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place a
mat under the treadmill. To order a mat, see the back cover of this manual.
5. Locate the holes on the left side of the treadmill frame
(1). If there are four holes, the two holes toward the
back of the treadmill are used to attach the Frame
Guides. Attach the Frame Guide (5) and the two
Frame Guide Spacers (116) to the Frame with two
Small Screws (4). Be careful not to overtighten the
Screws. Make sure that the thick end of the Frame
Guide is at the bottom.
Note: If it is difficult to fold or lower the treadmill,
remove one or both of the Frame Guide Spacers
(116).
5
1
4
116
Thick End
5
4. With the help of a second person, carefully raise the
Uprights (71) until the treadmill is in the position
shown.
71
4
Use these
holes.
