4
Location of Controls
KX-T7431
KX-T7436
MODE SELECT
KX-T 7431 SUPER HYBRID SYSTEM
MODE
LCD (Liquid Crystal Display)
SELECT
KX-T7433
SHIFT
KX-T 7433 SUPER HYBRID SYSTEM
LCD (Liquid Crystal Display)
Soft Buttons (S1 through S3)
SHIFT
FLASH/RCL
AUTO DIAL
STORE
AUTO ANSWER
MUTE
MESSAGE
SP-PHONE HOLD REDIAL
1 2 3 4 5 6
7 8 9 10 11 12
13 14 15 16 17 18
19 20 21 22 23 24
PROGRAM TRANSFER PAUSE FWD/DND INTERCOM CONF
ABC DEF
JKL MNO GHI
TUV WXYZ
OPER
PQRS
SHIFT
SUPER HYBRID SYSTEM
MIC
KX-T7436
LCD (Liquid Crystal Display) Function Buttons (F1 through F10)
Soft Buttons (S1 through S3)
Flexible
Outside (CO)
Line Buttons
INTERCOM
CONF (Conference)
FWD/DND (Call Forwarding/Do Not Disturb)
REDIAL HOLD
SP-PHONE (Speakerphone)
MIC (Microphone)
FLASH/RCL Jog Dial
AUTO DIAL
/STORE
SHIFT
PAUSE
MESSAGE
AUTO ANSWER/MUTE
PROGRAM
TRANSFER
* The KX-T7420 and KX-T7425 are non-display models.
