Panasonic SC-HT840 - Manual (Page 33)

33
RQT7978
Sp
ec
if
icat
io
n
s
[HT530] [Center\speaker\SB-PC730]
Type 2 way, 3 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Full range 6.5 cm Cone type
2. Full range 6.5 cm Cone type
3. Super Tweeter Piezo type
Input power (IEC) 160 W (Max)
Output sound pressure 83 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 103 Hz–25 kHz ( j16 dB)
116 Hz–22 kHz ( j10 dB)
Dimensions (W tHtD) 320 mm k88 mmk96 mm
Mass 1.3 kg
[HT530] [Active\subwoofer\SB-WA530]
Type 1 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 13 cm Cone type
2. Woofer 13 cm Cone type
Output sound pressure 80 dB/W (1.0 m)
Frequency range 40 Hz–220 Hz ( j16 dB)
45 Hz–180 Hz ( j10 dB)
Dimensions (W tHtD) 201.5 mm k368.2 mmk491.5 mm
Mass 11.3 kg
[HT840] [Front\speakers\SB-FS840]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 8 cm Cone type
2. Tweeter 6 cm Cone type
Input power (IEC) 70 W (Max)
Output sound pressure 81 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 78 Hz–45 kHz ( j16 dB)
90 Hz–35 kHz ( j10 dB)
Dimensions (W tHtD) 260 mm k1234 mmk270 mm
Mass 3.92 kg
[HT840] [Surround\speakers\SB-FS841]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 8 cm Cone type
2. Tweeter 6 cm Cone type
Input power (IEC) 70 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 70 Hz–45 kHz ( j16 dB)
85 Hz–35 kHz ( j10 dB)
Dimensions (W tHtD) 100 mm k324 mmk112 mm
Mass 1.06 kg
[HT840] [Center\speaker\SB-PC840]
Type 2 way, 3 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 6.5 cm Cone type
2. Woofer 6.5 cm Cone type
3. Tweeter 6 cm Cone type
Input power (IEC) 260 W §2 (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 110 Hz–45 kHz ( j16 dB)
140 Hz–35 kHz ( j10 dB)
Dimensions (W tHtD) 320 mm k88 mmk96 mm
Mass 1.36 kg
[HT840] [Active\subwoofer\SB-WA840]
Type 1 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 13 cm Cone type
2. Woofer 13 cm Cone type
Output sound pressure 80 dB/W (1.0 m)
Frequency range 40 Hz–220 Hz ( j16 dB)
45 Hz–180 Hz ( j10 dB)
Dimensions (W tHtD) 201.5 mm k368.2 mmk491.5 mm
Mass 11.3 kg
[HT880] [Front\speakers\SB-FS930]
Type 2 way, 3 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Woofer 8 cm Cone type
2. Woofer 8 cm Cone type
3. Tweeter 6 cm Ring shaped dome type
Input power (IEC) 170 W §2 (Max)
Output sound pressure 84 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 75 Hz–50 kHz ( j16 dB)
90 Hz–45 kHz ( j10 dB)
Dimensions (W tHtD) 260 mm k1234 mmk270 mm
Mass 4.35 kg
[HT880] [Surround\speakers\SB-FS880]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 8 cm Cone type
2. Tweeter 6 cm Ring shaped dome type
Input power (IEC) 70 W (Max)
Output sound pressure 81 dB/W (1.0 m)
Cross over frequency 7 kHz
Frequency range 78 Hz–50 kHz ( j16 dB)
90 Hz–45 kHz ( j10 dB)
Dimensions (W tHtD) 260 mm k1234 mmk270 mm
Mass 3.92 kg
[HT880] [Center\speaker\SB-PC930]
Type 2 way, 3 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 6.5 cm Cone type
2. Woofer 6.5 cm Cone type
3. Tweeter 6 cm Ring shaped dome type
Input power (IEC) 260 W §2 (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 110 Hz–50 kHz ( j16 dB)
140 Hz–45 kHz ( j10 dB)
Dimensions (W tHtD) 320 mm k88 mmk96 mm
Mass 1.36 kg
[HT880] [Active\subwoofer\SB-WA880]
Type 1 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 15 cm Cone type
2. Woofer 15 cm Cone type
Output sound pressure 84 dB/W (1.0 m)
Frequency range 34 Hz–220 Hz ( j16 dB)
38 Hz–190 Hz ( j10 dB)
Dimensions (W tHtD) 202 mm k410 mmk500 mm
Mass 13.7 kg
GENERAL
Power supply
[The\United\Kingdom,[Australia[and[N.Z.\ AC 230 j240 V, 50 Hz
[Others\ AC 110/127/220 j230/240 V, 50/60 Hz
Power consumption Main unit 25 W
[HT530] Subwoofer 250 W
[HT840] Subwoofer 340 W
[HT880] Subwoofer 390 W
Dimensions (W tHtD) 430 mm k60 mmk348.3 mm
Mass Main unit 2.7 kg
Operating temperature range r5 oC to r35 oC
Operating humidity range 5 % to 90 % RH (no condensation)
§2 Rating with low cut filter equipped amplifier
[Note]
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Power consumption in standby mode
[The\United\Kingdom,[Australia[and[N.Z.\
approx. 0.7 W
[Others] approx. 0.9 W
