32. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)

in the direction shown.

Attach the Pulley (35) and a Cable Trap (44) to the
lowest of the two holes in the Pulley Plates (31) hang-
ing from the High Cable (73). Secure the Pulley and
Cable Trap with a 3/8Ó x 2Ó Bolt (62) and a 3/8Ó Nylon
Locknut (50).

Make sure the Cable Trap is oriented as shown
and that it is mounted between the Pulley Plates.

33. Remove the 3/8Ó Nylon Locknut (50) that was thread-

ed onto the 3/8Ó x 4 3/4Ó Bolt (65) in step 31.

Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)
in the direction shown. Slide the Pulley and a Cable
Trap (44) onto the 3/8Ó x 4 3/4Ó Bolt (65). Secure the
Pulley with a 3/8Ó Nylon Locknut (50).

Make sure both Cable Traps attached to the 3/8Ó x
4 3/4Ó Bolt (65) are oriented as shown in this step
and in step 31.

32

33

31. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)

in the direction shown. Slide the Pulley and a Cable
Trap (44) onto a 3/8Ó x 4 3/4Ó Bolt (65). Slide the Bolt
into the indicated hole in the bracket on the Butterfly
Upright (2). Thread a 3/8Ó Nylon Locknut (50) a cou-
ple of turns onto the Bolt to prevent it from sliding out
during the following steps.

31

72

35

65

2

73

62

35

72

44

65

50

35

72

2

44

31

50

44

34. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35)

in the direction shown. Attach the Pulley and a Cable
Trap (44) to the ÒIÓ-plates (31) hanging from the Short
Cable (97). Secure the Pulley and Cable Trap with a
3/8Ó x 2Ò Bolt (62) and a 3/8Ó Nylon Locknut (50).

Make sure the Cable Trap is oriented as shown
and that it is mounted between the Pulley Plates.

34

62

97

44

31

72

35

50
