Technical Specifications
Plug and play compatibility
• Display Data Channel DDC 2B
• Microsoft
® Windows ® 95/98/Me & 2000/NT/XP compatible
Power management
Complies with EPA Energy Star and NUTEK specifications
• Operation 120
W (typical)
• Off mode/Deep Sleep < 1 W
Low-emission characteristics
• Complies with MPR-II and TCO ’03 specifications
Monitor controls and functions
• Main 5-button OSD
Brightness +/- direct access
Contrast+/- direct access
Input selection direct access
• On Screen Display Language (English, Spanish, French,
German, Italian), zoom, horizontal,
vertical, pincushion, balanced,
trapezoid, parallelogram, color, sRGB
reset, degauss, moire, serial number,
resolution, frequency
Convergence, purity
Input selection
Auto Calibrate
• Auto Calibrate Automatic and manual calibration of
color temperature, brightness and
contrast levels to original setting.
Connections and Cables
• Connections
-Video 15-pin D-sub / 5 BNC
• Cables D-Sub Video cable(fixed), power cord
Regulatory approvals
• TCO ‘03
• MPR-II Low Emission
• TÜV/GS,TÜV/Ergo
• FCC-B, UL, CSA, DHHS
• SEMKO, Poland-B sign, C-Tick
• VCC-I, CE, BSMI, PSB
Physical specifications
• Dim. incl. base (WxHxD)(mm) 456 x 469 x 438
• Dim. incl. base (WxHxD)(inch) 17.9" x 18.5" x 17.2"
• Dim. excl. base (WxHxD)(mm) 456 x 419 x 438
• Dim. excl. base (WxHxD)(inch) 17.9" x 16.5" x 17.2"
• Weight (kg)
23.5 kg
• Power supply 90 - 264 VAC, 50/60Hz
• Temperature (operational) 0°C to 35°C/ 32°F to 95°F
• Temperature (storage) -25°C to 65°C/ -13°F to 149°F
• Relative humidity 5% to 95%
• MTBF > 75,000 hrs
All data subject to change without notice
Release date: January 2004
www.philips.com As an Energy Star partner, Philips has determined that this product meets the Energy Star
guidelines for energy efficiency.
Brilliance is a registered trademark of Koninklijke Philips Electronics N.V.
Microsoft and Windows are registered trademarks of Microsoft Corporation
All trademark acknowledged. Copyright 2001 Koninklijke Philips Electronics N.V.
19" (18.0" VIS) Real Flat monitor
CRT
• Size (inch/cm) 19"/ 46 cm
• Deflection angle (degrees) 90°
• Grille pitch 0.24 mm uni-pitch
• Tube type Aperture grille, Real Flat, High
Contrast, Anti Glare, Anti Static,
Anti reflection
Light Transmission 41%
• Phosphor B22
• Recom. display area(mm) 355 x 265 mm
• Recom. display area(inch) 14" x 10.4"
• Max. display area(mm) 365 x 274 mm
• Max. display area(inch) 14.4" x 10.8"
Scanning
• Horizontal scanning 30 - 111 kHz
• Vertical scanning 50 - 160 Hz
Video
• Video dot rate 290 MHz
• Input impedance
-Video 75 Ohm
-Sync 2.2k Ohm
• Input signal levels 0.7 Vpp
• Sync input signal Separate sync
Composite sync
• Sync polarities Positive and negative
White color temperature
• at 9300°K: x=0.283, y=0.297
• at 6500°K: x=0.313, y=0.329
• at 5500°K: x=0.332, y=0.347
Resolution and preset modes
• Max. resolution 1920 x 1440
• Recom. resolution 1280 x 1024
• GTF
• 16 user definable modes
• 30 factory preset modes:
H.freq (kHz)/ V.freq (Hz)
640 x 480 31.5K/60
640 x 480 37.9K/72
640 x 480 37.5K/75
640 x 480 43.3K/85
640 x 480 50.6K/100
720 x 400 31.5K/70
800 x 600 37.9K/60
800 x 600 48.1K/72
800 x 600 46.9K/75
800 x 600 53.7K/85
800 x 600 63.9K/100
832 x 624 49.7K/75
1024 x 768 48.4K/60
1024 x 768 56.5K/70
1024 x 768 60.0K/75
1024 x 768 68.7K/85
1152 x 870 68.7K/75
1280 x 960 85.9K/85
1280 x 1024 64.0K/60
1280 x 1024 80.0K/75
1280 x 1024 91.1K/85
1600 x 1200 75.0K/60
1600 x 1200 81.3K/65
1600 x 1200 87.5K/70
1600 x 1200 93.8K/75
1600 x 1200 106.3K/85
1792 x 1344 83.6K/60
1792 x 1344 106.3K/75
1856 x 1392 86.3K/60
1920 x 1440 90.0K/60
