Power supply:
120V AC, 60 Hz
Power consumption: Approx. 67 W
Video output:
Composite signal 1.0 Vp-p/752 (BNC connector)
R/G/B, Y/PR/PB, Y/C signal (switch)1 each (BNC connector)
R,B: 0.7 Vp-p/75, G: 1.0 Vp-p/75 (with SYNC)
Y: 1.0 Vp-p/75, PR, PB: 0.7 Vp-p/75
Y: 1.0 Vp-p/75, C: 0.286 Vp-p/75
SYNC signal (Negative polarity) 2 Vp-p/751 (BNC connector)
S-Video signal Y: 1.0 Vp-p/75, C: 0.286 Vp-p/75 (S-Video connector)
The above values are the values which are cable-compensated by this unit after they has
been output from the camera at a regular level.
Genlock input:
1.0 Vp-p composite video signal or black burst signal/75 or High impedance (automatic
terminated BNC connector)
AUX input:
1.0 Vp-p composite video signal/75 or High impedance (automatic terminated BNC connector)
Pan/tilt head control input:
Pan/tilt head (up, down, right, left, defroster, wiper), lens (zoom, focus)
D-SUB 15-pin (female)
Switch function:
Gain up selection, AGC selection, color bar/camera selection, detail compensation selection,
auto white/auto black set, white balance selection, scene file, electronic shutter switch,
lens iris selection, subcarrier phase coarse adjustment, cable compensator selection, user set,
menu, item up, item down
Adjustment function:
R•B gain, R•B pedestal, total pedestal, lens iris adjustment, INCOM level, horizontal phase,
subcarrier phase finely adjustment, Y gain adjustment, chroma gain adjustment
TALLY/INCOM connector:
D-SUB 15-pin (female)
INCOM connector:
XLR 4-pin (male)
Maximum cable length:
984 ft. (300 m) (convertible camera unit)
328 ft. (100 m) (AW-E860 + AW-PB305 + Viewfinder)
Operating temperature:
14°F to 113°F (–10°C to +45°C)
Dimensions (WHD):
16-9/163-7/169-13/16 (42088250 mm)
(excluding protrusions)
Weight:
Approx. 12.3 lbs. (5.6 kg)
Finish:
AV ivory paint (color resembling Munsell 7.9Y 6.8/0.8)
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
