Philips 20HF7412 User Manual
Page 2
20HF7462/12
Professional flat TV with Crystal Clear III
20" LCD
Specifications
Product highlights
Display
•
Aspect ratio:
4:3
•
Brightness:
450 CD
•
Contrast ratio (typical):
350:1
•
Diagonal screen size:
20 inch / 51 cm
•
Display:
LCD VGA Active Matrix TFT
•
Picture enhancement:
Scan, 2D combfilter,
Sharpness adjustment, Active, Digital, Crystal
Clear III, Color Transient Improvement
•
Screen enhancement:
Anti-Reflection
•
Viewing Angle (H / V):
176 / 176 degree
•
Resolution:
640 x 480p
•
time:
25 ms
Sound
•
Sound:
NICAM
•
Sound:
Smart sound
•
Power:
2 x 5W
•
Music power:
20 W
Loudspeakers
•
Built in:
2
Convenience
•
Ease of Installation:
Fine Tuning, PLL Digital
Tuning, Program Name
•
Use:
Auto, Smart Picture Control, Sound, FM
radio, On Screen Display
•
Type:
RC2886
•
Teletext:
10 page Smart Text
•
Clock:
Sleep Timer, Wake up Clock
•
VESA Mount:
100 x 100 mm
•
Teletext enhancements:
4 favourite pages
•
Remote Control:
TV
Tuner
•
Tuner:
Hyper band, S channel, UHF, VHF, FM
•
TV system:
PAL, PAL, PAL, SECAM, SECAM,
SECAM
•
Video Playback:
NTSC, PAL, SECAM
•
Input:
ohm
•
Tuner:
PLL
•
Channels:
127
Connectivity
•
Scart:
Audio L/R, CVBS, RGB
•
Other connections:
Antenna, FM antenna
•
Front / Side connections:
Headphone out, S-video
in, CVBS in
•
Connectivity:
Connector, Connector
Power
•
Power:
55 W
•
Standby power consumption:
< 3 W
•
Ambient temperature:
+5°C/+45°C
•
Power:
AC 90V - 240V 50/60 Hz
Dimensions
•
Product dimensions (WxDxH):
477 x 435 x 86
•
Dimensions (with base) (H x D):
461 x 217 mm
•
Weight:
8 kg
•
Weight:
10 kg
•
Outer carton dimensions WxDxH:
580 x 528 x
185
•
Bezel color:
Silver Frost
Accessories
•
Included:
Table top stand, Remote Control,
Power, User manual
•
Issue date 2007-11-14
Version: 10.0
12 NC: 8670 000 20817
EAN: 87 10895 82862 8
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
Integrated clock display
The built-in clock display, which is also a wake-up alarm,
eliminates the need and investment for an additional
clock with cables and connections in the room. Automatic
time synchronisation via teletext and preservation of
alarm settings during short power outages further
enhances guest comfort
Wireless
wireless
Welcome message
Volume limitation
This feature predefines the volume range with which the
TV set is allowed to operate, preventing excessive volume
adjustments and avoiding disturbance of next door
guests.
Front Controls Locking
Prevents unauthorised access to TV functions
Switch On Channel Programming
Perfect for in-house advertising or information channels
as it allows to show a predefined channel when the TV is
turned on.
Security Menu Access
Provides conditional access to installation and
configuration settings via a special code or master remote
control
Built-in FM radio
The integrated FM radio offers guests additional comfort
without the extra investment in radio receivers.
SmartCard Xpress Box
The optional SmartCard Xpress Box can be mounted at
the rear side of the TV set and allows third party decoders
and application cards to interface with the TV adding new
functionality to the TV. The TV can also be connected to
external decoders and set-top boxes of all major
interactive system providers, through the Serial Xpress
Control Interface (supporting UART and RS232
protocols) and the SmartPlug Control interface.
Add. integrated power supply
The additional integrated power supply avoids the need
for a separate power supply for an interactive system. In
case of stand-alone use, the additional power supply can
be switched off to save energy.
Serial Xpress™ Control
The Serial Xpress™ Control interface is compatible with
all major premium entertainment services. The protocols
enables the TV connection with external decoders, set-top
boxes and PC based solutions. Support UART and RS232
protocols.
Upgradable software
The upgradable software architecture ensures that the
TV is future-proof and compatible with new technologies
and developments, securing your investment.
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture. They include a
2D Comb filter, Dynamic contrast, Blue stretch and
Green enhancement so that you always get the most
natural looking colours.
LCD VGA display, 640 x 480p
This VGA display with state-of-the-art LCD screen
technology has an enhanced resolution of 640 x 480p.
2D combfilter
The 2D comb filter separates chrominance (colour) from
luminance (brightness) information in the video signal for
independent processing to improve picture resolution and
minimise distortion.
