page 8
After unpacking the treadmill, open the hardware kit (refer to Diagram 1) and make sure that you
have the following items:
(A) four frame-to-base plate bolts
(B) two water bottle cage mounting bolts
(C) two lower handrail clamp bolts
(D) four split star washers—place on frame-to-base bolts
(E) four internal star washers—2 for lower handrail clamps/2 for mounting water bottle cage
(F) one 5/16" hex key—frame-to-base bolts
(G) one 1/4" hex key—belt tracking and tension adjustment
(H) one 3/16" hex key—upper handrail bolts
( I ) one 5/32" hex key—lower handrail clamp and water bottle cage
(J) two lower handrail clamps
(K) one magnetic safety key assembly
(L) one water bottle cage
If any items are missing, contact the dealer from whom you purchased the treadmill or call
1-800-4-PRECOR for the dealer nearest you.
G
F
H I
E
D
J
K
L
Diagram 1
Hardware Kit. A B C
