3
CUTTING SAFETY
WARNING:
Inspect the area before
each use. Remove objects (rocks, broken
glass, nails, wire, etc.) which can be thrown
by or become entangled in line. Hard objects
can damage the trimmer head and be thrown
causing serious injury.
S
Use only for trimming, scalping, mowing and
sweeping. Do not use for edging, pruning or
hedge trimming.
S Keep firm footing and balance. Do not
overreach.
S Keep all parts of your body away from muffler
and spinning line. Keep engine below waist
level. A hot muffler can cause serious burns.
S Cut from your left to your right. Cutting on
right side of the shield will throw debris away
from the operator.
S Use only in daylight or good artificial light.
S Use only for jobs explained in this manual.
TRANSPORTING AND STORAGE
S Allow engine to cool; secure unit before
storing or transporting in vehicle.
S Empty the fuel tank before storing or
transporting the unit. Use up fuel left in the
carburetor by starting the engine and letting it
run until it stops.
S Store unit and fuel in area where fuel vapors
cannot reach sparks or open flames from
water heaters, electric motors or switches,
furnaces, etc.
S Store unit so line limiter blade cannot
accidentally cause injury. The unit can be
hung by the shaft.
S Store unit out of reach of children.
SAFETY NOTICE: Exposure to vibrations
through prolonged use of gasoline powered
hand tools could cause blood vessel or nerve
damage in the fingers, hands, and joints of
people prone to circulation disorders or abnor-
mal swellings. Prolonged use in cold weather
has been linked to blood vessel damage in
otherwise healthy people. If symptoms occur
such as numbness, pain, loss of strength,
change in skin color or texture, or loss of feeling
in the fingers, hands, or joints, discontinue the
use of this tool and seek medical attention. An
anti--vibration system does not guarantee the
avoidance of these problems. Users who oper-
ate power tools on a continual and regular basis
must monitor closely their physical condition
and the condition of this tool.
SPECIAL NOTICE: This unit is equipped
with a temperature limiting muffler and spark
arresting screen which meets the require-
ments of California Codes 4442 and 4443. All
U.S. forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey, Ore-
gon, and Washington require by law that
many internal combustion engines be
equipped with a spark arresting screen. If you
operate in a locale where such regulations ex-
ist, you are legally responsible for maintaining
the operating condition of these parts. Failure
to do so is a violation of the law. For normal
homeowner use, the muffler and spark arrest-
ing screen will not require any service. After
50 hours of use, we recommend that your
muffler be serviced or replaced by your autho-
rized service dealer.
ASSEMBLY
WARNING:
If received assembled,
repeat all steps to ensure your unit is properly
assembled and all fasteners are secure.
Examine parts for damage. Do not use dam-
aged parts.
NOTE: If you need assistance or find parts
missing or damaged, call 1-800-554-6723.
It is normal for the fuel filter to rattle in the
empty fuel tank.
Finding fuel or oil residue on muffler is normal
due to carburetor adjustments and testing
done by the manufacturer.
ATTACHING THE ASSIST HANDLE
WARNING:
When attaching the assist
handle, be sure it remains above the safety label
and below the arrow on the shaft.
1. Place unit on a flat surface.
2. Loosen and remove wing nut and bolt
from assist handle.
3. Firmly push the assist handle over the
shaft.
4. Reinstall bolt in handle. Thread wing nut
onto bolt. Tighten securely.
ATTACHING THE SHIELD
WARNING:
The shield must be prop-
erly installed. The shield provides partial protec-
tion from the risk of thrown objects to the opera-
tor and others and is equipped with a line limiter
blade which cuts excess line to the proper
length. The line limiter blade (on underside of
shield) is sharp and can cut you.
For proper orientation of shield, see KNOW
YOUR TRIMMER illustration in OPERATION
section.
1. Remove wing nut from shield.
2. Insert bracket into slot as shown.
3. Pivot shield until bolt passes through hole in
bracket.
4. Securely tighten wing nut onto bolt.
Wing Nut
Bracket
Slot
Shield
Gearbox
PIVOT
