M10 x 78mm Carriage Bolt (50)

M10 Nylon Locknut (64)

M6 x 25mm Button Screw (57)

M6 x 38mm Button Screw (53)

M10 x 22mm Bolt Set (66)

M4 x 25mm Round Head Screw (47)

M4 x 16mm Screw (76)

M6 x 25mm Screw (77)

M6 x 16mm Screw (55)

M6 x 45mm Screw (78)

PART IDENTIFICATION CHART

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.

Note: Some small parts

may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
