Pride Mobility 1170 XL Plus - Manual (Page 2)

JZBAR-9-6-11
(US) 800-800-8586
.
(Canada) 888-570-1113
.
www.pridemobility.com
The information contained herein is correct at the time of publication; we reserve the right to alter specifications
without prior notice. Speed and range vary with user weight, terrain type, battery charge, battery condition and tire
pressure. Due to manufacturing tolerances and continual product improvement, length, width, turning radius and
ground clearance can be subject to variance of + or – 3 %. Special order seats or non-standard dimensions will
not be fold-flat and depth-adjustable.
500 lbs.
Up to 5 mph
4”
26.75”
45.25”
30”
16” solid
8” solid
9” solid
Active-Trac ® suspension
Two-motor, mid-wheel drive
Intelligent braking
(electronic, regenerative disc brakes)
70 amp, PG VSI controller
Off-board, 5 amp
Up to 15 miles
(2) 12 volt, deep cycle (gel cell or AGM)
Group 24
53.5 lbs. each
149.5 lbs.
42.5 lbs. (high-back)
28” x 26”
Candy Apple Red, Viper Blue, Onyx Black,
Champagne
2VHD-SS (K0826), 2VHD-C (K0827)
3VHD-SS (K0852), 3VHD-C (K0853)
K0826/K0827 Models:
Lifetime limited warranty on frame;
13-month limited warranty on electronics;
13-month limited warranty on drive motors
K0852/K0853 Models:
Lifetime limited warranty on frame;
2-year limited warranty on electronics;
18-month limited warranty on drive motors
Weight capacity
Maximum speed
Ground clearance
Turning radius
Overall length
Overall width
Drive wheels
Front anti-tips
Rear casters
Suspension
Drivetrain
Braking system
Standard electronics
Std. battery charger
Per-charge range
Battery requirements
Battery size
Battery weight
Base weight
Standard seat weight
Max. seat dimensions
Colors
Available models
Warranty
Jazzy ® 1170 XL PLUS Jazzy ® 1420 Jazzy ® 1650
500 lbs.
Up to 4.5 mph
4.5”
25.75”
46”
27.25”
16” solid or pneumatic
8” solid
9” solid or pneumatic
Active-Trac ® w/ rear caster suspension
Two-motor, mid-wheel drive
Intelligent braking
(electronic, regenerative disc brakes)
70 amp, PG VR2 controller
Off-board, 8 amp
Up to 20 miles
(2) 12 volt, deep cycle (gel cell or AGM)
Group 24
53.5 lbs. each
141.5 lbs.
42.5 lbs. (high-back)
24” x 24”
Candy Apple Red, Viper Blue, Onyx Black,
Champagne, Sunburst Orange
2HD-SS (K0824), 2HD-C (K0825)
2VHD-SS (K0826), 2VHD-C (K0827)
3VHD-SS (K0852), 3VHD-C (K0853)
K0824/K0825/K0826/K0827 Models:
Lifetime limited warranty on frame;
13-month limited warranty on electronics;
13-month limited warranty on drive motors
K0852/K0853 Models:
Lifetime limited warranty on frame;
2-year limited warranty on electronics;
18-month limited warranty on drive motors
650 lbs.
Up to 5 mph
4.25”
26.25”
47”
30.375”
16” solid or pneumatic
8” solid
9” solid or pneumatic
Limited
Two-motor, 4-pole, in-line mid-wheel drive
Intelligent braking
(electronic, regenerative disc brakes)
100 amp, PG Remote Plus controller
Off-board, 8 amp
Up to 15 miles
(2) 12 volt, deep cycle (gel cell or AGM)
Group 24
53.5 lbs. each
176 lbs.
75 lbs. (high-back)
32” x 28”
Candy Apple Red, Viper Blue, Onyx Black,
Champagne
3EHD-SS (K0854)
3EHD-C (K0855)
Lifetime limited warranty on frame;
2-year limited warranty on electronics;
18-month limited warranty on drive motors
