PART IDENTIFICATION CHART

Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
refers to the key number of the part, from the PART
LIST on page 14. The number after the dash indicates

the quantity needed for assembly. Note: Some parts
may have been pre-attached for shipping. If a part
is not in the parts bag, check to see if it has been
pre-attached.

Pedal Arm Spacer (41)—2

M6 x 16mm Screw (54)—2

M4 x 19mm Flange

Screw (16)–6

M4 x 16mm Screw

(34)—5

Weld Spacer (49)—2

5/8” Axle Cap (57)—2*

3/4” Axle Cap (43)—4*

M10 Nylon Locknut (29)—4

M6 Black Nylon Locknut (55)—2

Handlebar Spacer (39)—2

Rear Pedal Arm Bushing (11)—8

* Extra parts may be included.
